Transformer Short-Circuit Impedance Tester

Product Introduction

The DC resistance test of transformer windings is an important test item after transformers are handed over, overhauled, or the tap changers are altered. Traditional methods such as the Wheatstone bridge and voltage drop methods for measuring the DC resistance of transformer windings and high-power inductive equipment are not only time-consuming and labor-intensive but also inefficient. To meet the testing needs of modern power systems, Wuhan Xinhuafu Electric Power Equipment Co., Ltd. has developed the DC Resistance Rapid Tester. This tester stands out for its efficiency, accuracy, and convenience, making it an ideal choice for measuring the DC resistance of transformer windings and high-power inductive equipment.

This direct current resistance rapid tester is strictly in accordance withDL/T845.3-2004In compliance with national standardsGB6587"Outline for Environmental Testing of Electronic Measuring Instruments"GB6593The design and production are in compliance with the requirements of the "Regulations for the Inspection and Verification of Electronic Instruments," ensuring product stability and reliability.

Product Features

Efficient and Stable Output: This tester can reliably output up to40ADirect current (DC) current is ensured for rapid and stable measurement processes.Extreme.Significantly boosted testing efficiency.

High-Capacity Storage Function: Built-in High-CapacityCPUEasily stored255Group measurement results for easy access to historical data by users, facilitating comparisons and analysis.

Intuitive and Simple Operation Interface: With a large LCD screen and full Chinese menu guidance, the operation is intuitive and straightforward, allowing even non-specialists to easily get started.

Safety Protection Features: Equipped with automatic discharge and discharge indicator functions, effectively reducing accidental operations and ensuring the safety of test personnel and equipment.

Portable Design: The tester features a vertical cabinet design, offering high output current with a light weight, making it convenient for users to carry to the site for testing.

Print Function: Equipped with a panel-mounted mini printer, it can print measurement results in Chinese, facilitating users to record and analyze test data.

Data Review & Printing: Stored test results are not only accessible for review but can also be printed at any time, facilitating report writing and data analysis for users.

Wuhan Xinhua Fu Electric Equipment Co., Ltd.'s DC resistance rapid tester boasts its...Zhuo.No Chinese content provided. Please provide the text to be translated.The superior performance and user-friendly design provide robust support for power system testing, making it an indispensable testing tool in the power industry.
