Frequency-converted series resonant voltage withstand

Product Introduction

The non-dispersive变频串联谐ronic resonator is primarily used to test the insulation levels of various insulating materials, structures, and electrical products for their ability to withstand power frequency voltages. It also serves as a power source for non-local discharge power frequency tests for samples such as transformers, current transformers, and lightning arresters. Widely applied in electrical manufacturing departments, power operation departments, research institutions, and colleges and universities. Applicable objects: high-voltage electrical equipment, such as transformers,GISTransformer, switchgear, sleeves, lightning arresters, cable partial discharge and AC withstand tests; insulation material's working frequency AC withstand voltage.

Product Alias

No-break AC voltage resonance device, variable frequency resonance, variable frequency series resonance, series resonance, series resonance transformer, variable frequency series resonance voltage equipment for electrical equipment, series resonance test equipment

Product Features

1Set packages have limited bulk release, ensuring that the system's bulk release is minimal.5pCWithin scope (special requirements available upon request)

2The outer casing is made of an epoxy resin casting with glass fiber winding, featuring a non-glare high-voltage insulated cylinder.

3The complete set of equipment boasts low impedance, overvoltage and overcurrent arc protection, and is equipped with comprehensive functions, ensuring high reliability.

4The pressure cover is precision-molded, made from aluminum sheets, with a smooth surface, lightweight, and easy to install.

5The high-voltage, high-capacity test device achieves a higher level of system control, protection, and operation intelligence and automation through the selection of a power frequency intelligent measurement and control system.

6Utilizing fiber optic communication and sampling, we have completely isolated the high-voltage and low-voltage control circuits.

7The testing process features real-time self-inspection and display capabilities.

8Comprehensive data and report management capabilities

9Record and draw high-voltageU/T、I/T Test Curve
