SF6 Vacuum Filling Equipment

Product Introduction: Gas Recovery and Refilling Unit

With the development of modern industry,SF6Gases, as an efficient insulating and arc quenching medium, are widely used in electrical equipment. However, due to their high cost and the production of toxic components under certain conditions, they present challenges.SF6Effective management and handling of gases have become crucial. To this end, we have launched...Six Fluoride.DesulfurizationGas Recovery Filling Equipment, a specialized unit for manufacturing and maintenanceSF6Electrical Equipment Recycling and RefuelingSF6Specialty equipment for gas design.

Product Features

Multi-functional IntegrationThe device integrates functions such as collection, refilling, purification, vacuum extraction, storage, and bottling, providing users with a one-stop solution.SF6Gas Management Solutions.

User-friendlyThrough the electrical control box on one side of the panel and the ball valve, users can easily achieve the series connection or switching of various functions, significantly enhancing operational efficiency.

Efficient RecyclingThe facility utilizes cryogenic liquefaction technology, taking advantage of the suction and compression properties of the compressor, to quickly and efficiently液化：SF6Gas recovery and liquefaction storage within electrical equipment.

Safe Charging and DischargingDuring the charging process, the device first draws a vacuum from the equipment or the connecting pipeline to ensure the safety and accuracy of the charging process.

Environmental DesignInstalled in recycling and processingSF6In the process of gas handling, we strictly adhere to environmental protection standards to ensure no harm to the environment or operators.

AdaptiveThe device is suitable for various voltage levels.SF6Electrical equipment offers stable and reliable performance, whether it's for recycling or recharging.

Operation Principle

During the recycling process, the compressor's suction and compression properties are utilized.SF6Gas is inhaled and compressed to a higher pressure. Simultaneously, the low evaporation temperature characteristic of the refrigerant is utilized to reduce high temperatures.SF6The gas is cooled to condensation temperature for liquefaction and storage. During the filling and emptying process, a vacuum pump is used to evacuate the equipment or cylinders, followed by utilizing the pressure difference or the suction capacity of the compressor to液化SF6Gas is filled into equipment or cylinders.

In summary,The gas recovery and refueling unit stands out for its high efficiency, safety, and environmental friendliness.SF6Electrical equipment manufacturing and maintenance receive robust support.
