SF6 Gas Comprehensive Detector

SF6Primary Functions of the Gas Leak Detection and Alarm System

Live DisplaySF6Gas Concentration

The system continuously collects and displays data from the detected area.SF6Gas concentration.

Real-time updates on the operational control panel and backend monitoring computersSF6Concentration level.

Users can set alarm concentrations as needed.

Real-time Oxygen Concentration Display

In inspectionSF6Simultaneously, the system also monitors oxygen levels.

Real-time oxygen concentration is displayed on the operational control panel and backend monitoring computers.

The oxygen alarm concentration can be set according to user requirements.

Alarm Output

WhenSF6Upon reaching the preset alarm level for oxygen concentration, the operation control panel will emit sound, light, and voice alarms.

The system will notify the remote monitoring center via software agreements or direct connections.

According to the settings, the system will automatically activate the fans for ventilation.

Infrared Sensing with Voice Alarms and Alerts

When someone approaches the switch room, the infrared sensor is activated.

The operational control panel will issue voice prompts to notify staff of the current conditions within the room.SF6Please check the oxygen levels and recommend entering after the fan is turned on for ventilation.

Wind Turbine Control

There are three methods of starting the fans: timed, alarm, and forced.

Users can set4A scheduled start time and duration.

When reaching the alarm concentration, users can choose to automatically activate the fan.

The operational control panel features buttons to manually start or shut down the fan.

Humidity and Temperature Display

Temperature Range Displayable by the System:-40～60℃。

The system displays a humidity range:0～100.%RH。

Sound and Light Alarm Control

Users can set the sound and light alarm to automatically turn off after a certain period of time to minimize the impact on the surroundings.

Detection Area

System capable of multi-detection24A regional solution, suitable for multiple switchgear rooms, helps to reduce user investment costs.
