SF6 Gas Online Monitoring and Alarm System

SF6Primary Function of Gas Leak Detection and Alarm System

Real-time displaySF6Gas Concentration

The system continuously collects and displays data from the detected area.SF6Gas Concentration.

Real-time updates on the operation control panel and backend monitoring computersSF6Concentration levels.

Users can set alert concentrations as needed.

Real-time Oxygen Concentration Display

In the inspectionSF6Simultaneously, the system also monitors oxygen content.

Real-time oxygen concentration is displayed on the operation control panel and backend monitoring computers.

The oxygen alarm concentration can be set according to user requirements.

Alarm Output

WhenSF6Should the oxygen concentration reach the preset alarm level, the operational control panel will emit audio-visual and voice alarms.

The system will notify the remote monitoring center via software agreements or dry contacts.

In accordance with the settings, the system automatically activates the fans for ventilation.

Infrared Sensing with Voice Alarms and Alerts

An infrared sensor is activated when someone approaches the switch room.

The operational control panel will emit voice prompts to notify staff of the current conditions within the room.SF6Please ensure proper oxygen levels, and recommend entering after the fan has been turned on for ventilation.

Fan Control

There are three startup methods for the windmill: timed, alarm, and forced.

Users can set4A scheduled start time and duration.

At alarm concentration levels, users can choose to activate the fan automatically or not.

The operational control panel features buttons to force-start or shut down the fans.

Humidity and Temperature Display

System temperature range displayable:-40～60℃。

System displays humidity range:0～100.%RH。

Sound and Light Alarm Control

Users can set the sound and light alarm to automatically turn off after a certain period of time after activation to minimize disturbance to the surrounding area.

Detection Area

System capable of multi-detection24A regional solution, suitable for multiple switchgear rooms, helps reduce user investment costs.
