Equipment Name:Self-adjustable roller stand, adjustable roller stand, welded roller stand, lifting roller stand, hydraulic tilt roller, long cylinder roller stand, hydraulic alignment roller stand, walking roller stand, wind tower roller standAnti-skid rolling stand

Application Scenario:Boiler Pressure Vessel Manufacturing、Petroleum & Chemical Equipment Manufacturing、Wind Power Equipment Manufacturing、Shipbuilding and Marine Engineering、Structural steel fabrication、Other heavy machinery manufacturing

Text Description:Different types of welding roller stands have varying technical specifications; for example, those from Wuxi Lida Welding Machinery Co., Ltd.The HGZ self-adjustable roller stand, for instance, has a load capacity ranging from 3 to 200 tons and is suitable for workpieces with diameters of 500 to 8000mm. The rotational speed is adjustable from 0.2 to 2m/min, with motor power options from 1.5kW to 15kW.

Features and Advantages

· Enhance welding qualityEnsures smooth rotation of workpieces, compatible with automatic welding equipment for achieving automatic welding, ensuring consistent weld quality, and reducing welding defects.

· Reduce labor intensityNo manual turning of workpieces required, reducing labor intensity and improving efficiency.

· Versatile: Can be assembled and welded into conical, segmented unequal diameter rotaries based on the weight and length of the welding pieces, with the ability to adjust roller height for versatility.

· High-precision synchronous controlSome roller stands are equipped with dual-motor independent drive technology.PLC control system achieves extremely small speed difference between the two wheels, ensuring smooth rotation of the workpiece.

· Energy-saving and consumption reductionSome roller stands achieve significant energy savings through optimized motor power matching compared to traditional equipment.
