Introduction:The SYH series of 3D motion mixing machines are widely used in pharmaceuticals, chemicals, food, metallurgy, light industry, and scientific research units. They can uniformly mix materials with good fluidity, such as powders or granules, resulting in an optimal mixing state of the mixed materials.

Detailed Description: The multi-directional movement of the mixing drum allows for numerous cross-mixing points within the drum, resulting in high mixing efficiency with uniformity exceeding 99.9%. The high loading coefficient reaches up to 0.9 (compared to 0.4-0.6 for standard mixers), with short mixing time and high efficiency.

This machine features a unique mixed drum design, with the inner wall meticulously polished for a smooth finish, eliminating dead corners and preventing material contamination. It offers ease of discharge, easy cleaning, and simple operation.

Operating Principle:

The machine operates with a multi-directional rotation of the mixing drum, which accelerates the flow and diffusion of various materials during the mixing process. At the same time, it avoids the segregation and accumulation of materials due to centrifugal force, common in conventional mixers. The mixing is thorough with no dead spots, ensuring the optimal quality of the mixed materials.

Structure: The machine is composed of the base, transmission system, electrical control system, multi-directional motion mechanism, and mixing drum, etc. The mixing drum, which comes into direct contact with the material, is made of high-quality stainless steel and both the inner and outer walls are mirror-polished.
