• Maximum resolution up to 2560 × 1440 @ 25 fps
• Supports SmartIR to prevent infrared overexposure at night
• Backlight compensation supported, strong light suppression, 3D digital noise reduction, digital wide dynamic range, adaptable to various usage environments
• Supports open network video interface, ISAPI, SDK, GB28181 protocol
• 1 built-in microphone
• Smart Fill Light, supports dual illumination with white light/IR
• Compliant with IP67 dust and water resistance design, high reliability
Video
Maximum Resolution:
2560 × 1440
Main Stream Frame Rate Resolution:
50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：25 fps（768 × 432，640 × 480，640 × 360）
Video Compression Standard:
Main Stream: H.265/H.264/Smart264/Smart265, supports super intelligent encoding; Sub Stream: H.265/H.264
Video Compression Bitrate:
32 Kbps~8 Mbps
H.264 Encoding Type:
baseLine Profile/Main Profile/High Profile
H.265 Encoding Type:
Main Profile
Bit Rate Control
Set fixed bit rate, variable bit rate
Event
Routine Event:
Motion Detection (supports human shape detection), Anomaly
Audio
Audio Environmental Noise Filtering:
Support
Audio Sampling Rate:
8 kHz/16 kHz
Audio Compression Standards:
G.711alaw/AAC-LC
Audio Compression Bitrate:
64 Kbps（G.711alaw）/16~64 Kbps（AAC-LC）
Network Transmission
Simultaneous preview options:
Up to 6 channels
User Management:
Up to 32 users, customizable with administrators, operators, and regular users.
Client:
iVMS-4200
Browser:
Use Local Service Preview: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
Interface Protocol (API):
Open network video interface, ISAPI, SDK, GB28181
Network Protocol:
TCP/IP，ICMP，HTTP，DHCP，DNS，RTP，RTSP，RTCP，NTP，IGMP，QoS，UDP，Bonjour，SSL/TLS，HTTPS，DDNS，UPnP，IPv4
Day/Night Transition Mode
Day and night, automatic and timed switching
Image Enhancement:
Backlight compensation, strong light suppression, 3D digital noise reduction
Image Settings:
Mirror, saturation, brightness, contrast, sharpness, AGC, white balance adjustable via client or browser
Interface
Audio:
1 built-in microphone
Internet:
1 RJ45 10/100 Mbps auto-sensing Ethernet port
Camera
Sensor Type:
1/2.7" Progressive Scan CMOS
Minimum Luminance:
Color: 0.005 Lux
Shutter:
1/3 s~1/100,000 s
Day/Night Switch Mode
ICR Infrared Filter Sheet
Wide Dynamic Range
Digital Wide Dynamic Range
Lens
Focal Length & Field of View:
4 mm: Horizontal Field of View: 70°, Vertical Field of View: 35°, Diagonal Field of View: 85°; 6 mm: Horizontal Field of View: 46°, Vertical Field of View: 24°, Diagonal Field of View: 54°; 8 mm: Horizontal Field of View: 43°, Vertical Field of View: 24°, Diagonal Field of View: 50°; 12 mm: Horizontal Field of View: 27°, Vertical Field of View: 15°, Diagonal Field of View: 31°
Maximum Aperture Number:
F2.0
Lens Size Interface:
M12
Fill light
Infrared wavelength range:
850 nm
Anti-overexposure protection:
Support
Lighting Type:
Intelligent lighting supplement, with options for switching to white light and infrared light.
Lighting Distance:
Infrared light reaches up to 50 m, while white light extends to 30 m.
Certification
Protection:
IP67
Standard Specifications
Startup and operating temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Storage temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Leveraging Method:
Upload Center
Universal Functions:
Heartbeat, password protection, watermark technology
Restore to factory settings:
Supports client or browser recovery
Power Supply Method:
DC: 12V ± 25%, with reverse polarity protection; PoE models supported: IEEE 802.3af, Class 3
Current and Power Consumption:
DC: 12V, 0.42A, Max Power Consumption: 5W PoE Supported: IEEE 802.3af, Class 3, Max Power Consumption: 6.5W
Power Interface Type:
5.5 mm round hole
Product Dimensions:
87.1 × 83.7 × 171.7 mm
Packaging Dimensions:
216 × 121 × 118 mm
Equipment Weight:
360 g
Net Weight with Packaging:
540 g
