• Featuring a 4.3-inch LCD touch screen, supports local video preview, and real-time face detection.
• Storage Capacity: Local support for 1,500 face databases, 3,000 cards, 3,000 fingerprints (-F model), and 150,000 event records.
• Utilizes deep learning algorithms for facial recognition at a distance of 0.3m-2.0m, with a face matching time of <0.2s per person and an accuracy rate of ≥99%; also supports photo and video anti-fake features.
• Equipped with a 20MP wide-angle dynamic camera, featuring a starry-level image sensor, capable of recognizing in low-light conditions.
• Supports various authentication methods including facial recognition, card swipe (Mifare/IC card, mobile NFC card, CPU card serial number, ID card serial number), password, fingerprint, QR code, and combinations such as facial recognition + fingerprint, facial recognition + card swipe, facial recognition or fingerprint or card swipe or password, and facial recognition + fingerprint + card swipe, etc. Flexible in pairing, suitable for different security level applications; (Different models may have different recognition modes, please refer to the actual device.)
• Supports mask recognition mode configuration, with options for reminder or mandatory mask-wearing modes.
• Supports configuration of room number for call, or one-touch call to indoor unit or control unit; supports two-way communication with indoor unit or control unit; supports auxiliary door intercom or fence intercom mode.
• Supports mobile and PC web operations, allows for personnel management, intelligent configuration, access control parameters, and other settings, convenient and quick, no need to rely on platform software.
• Supports integration with the Hikvision Interconnect APP, enabling cloud-based access control, attendance, and intercom functions, as well as one-touch door opening and attendance management configuration applications.
• The device supports local management, including local registration of faces, inquiries, settings, management of device parameters, local attendance configuration, and features such as local modification of the administrator's password, M1 card, and NFC on/off.
• Supports voice announcement on the device when remotely unlocking, to conveniently alert on-site personnel that the door has been opened
• Equipment supports custom voice announcements upon successful or failed certification results. You can input custom text to be converted into voice announcements or choose to import custom audio files (WAV format).
• Equipment supports importing/exporting encrypted data via USB flash drive to ensure data security.
• Supports Standby Ad Mode, Simple Mode, and Theme Mode
• External Security Module: Supports connecting to a private RS485 interface for access control security modules, preventing the door lock from being opened when the host is maliciously damaged.
• Card Reader Mode: Supports connecting to access control systems via dealer private RS485 or Wiegand (W26/W34/W27/W35) for use as a card reader.
• Multi-factor authentication, supporting door access with combinations of multiple people or a combination of multiple people with remote unlocking via the backend.
Screen Specifications
Dimensions:
4.3-inch vertical screen
Operation Method:
Touch Operation
Video Parameters
Pixel:
200w
Audio Parameters
Sound Quality:
Noise suppression and echo cancellation supported
Network Parameters
Wired Network:
Support
Wireless Networking:
WiFi/TCPIP
Physical Interface
Network Port:
1 RJ45
Door Lock Export
1 piece
Door Opener Button
1 piece
Magnetic door sensor input:
1 piece
IO Input:
0
IO Output:
0
Anti-theft:
Support
RS-485：
1 unit
Weggen:
1 piece
USB：
1 piece
Certification Parameters
Card Reading Type:
M1 Card; CPU Card Serial Number; 2nd and 3rd Generation ID Card Serial Number
Functional Parameters
Real Person Verification
Support photo/video anti-counterfeiting
Voice Broadcast:
Supported
Time Setting Function:
Support
Other Parameters
Ingress Protection (IP) Rating:
IP 65 - Suitable for indoor and outdoor use
