• Maximum resolution up to 1920 × 1080 @ 25 fps, capable of outputting real-time images at this resolution
• Smart Detection: Supports boundary detection, zone intrusion detection
• Backlight compensation, strong light suppression, 3D digital noise reduction, 120 dB wide dynamic range for various environments
• 1 built-in microphone
• Supports dual illumination with white light/IR, with IR light reaching up to 50m and white light up to 30m
• Meets IP66 dustproof and waterproof design, high reliability
Video
Maximum Image Size:
1920 × 1080
Main stream frame rate resolution:
50 Hz：25 fps（1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：25 fps（640 × 480，640 × 360）
Video Compression Standards:
Main Stream: H.265/H.264, supports Super Smart Coding; Sub Stream: H.265/H.264/MJPEG
Video Compression Bitrate:
32 Kbps~8 Mbps
H.264 Encoding Type:
baseLine Profile/Main Profile/High Profile
H.265 encoding type:
Main Profile
Smart264 Encoding:
Primary Stream Supported
Bit Rate Control
Set bitrate, variable bitrate
ROI：
Support for setting 1 fixed region for the main stream
Event
Alarm Trigger:
Motion Detection (Supports Human Detection), Anomaly
Smart Event:
Area intrusion detection, boundary detection
Audio
Audio Environmental Noise Filtering:
Support
Audio Sampling Rate:
8 kHz/16 kHz
Audio Compression Standards:
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Audio Compression Bitrate:
64 Kbps（G.711ulaw/G.711alaw）/16 Kbps（G.722.1）/16 Kbps（G.726）/32~160 Kbps（MP2L2）/16~64 Kbps（AAC-LC）
Network Transmission
Simultaneous preview routes:
Up to 6 channels
User Management:
Up to 32 users, configurable as administrators, operators, and regular users
Client:
iVMS-4200
Browser:
Use Local Service Preview: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
Interface Protocol (API):
Open network video interface, ISAPI, SDK, GB28181
Network Protocol:
TCP/IP，ICMP，HTTP，FTP，DHCP，DNS，RTP，RTSP，RTCP，NTP，SMTP，IGMP，QoS，UDP，Bonjour，IPv4，IPv6
smartIR：
Supported
Day/Night Mode Switch
Day and night, automatic and timed switching
Image Enhancement:
Backlight compensation, strong light suppression, 3D digital noise reduction
Image Settings:
Mirror, Corridor Mode (rotating), Saturation, Brightness, Contrast, Sharpness, White Balance adjustable via client or browser.
Interface
Audio:
1 built-in microphone
Internet:
1 RJ45 10/100 Mbps Auto-sensing Ethernet Port
Camera
Sensor Type:
1/2.7" Progressive Scan CMOS
Minimum Illuminance:
Color: 0.005 Lux
Shutter:
1/3 s~1/100,000 s
Slow shutter speed
Support
Part Number System
P-Grade
Wide Dynamic Range
120 dB
Day and night switch mode:
ICR Infrared Filter Sheet
Lens
Lens Size Interface:
M12
Aperture Type:
Fixed Aperture
Maximum Aperture Number:
F1.6
Depth of field range:
2.8 mm: 1 m~∞ 4 mm: 1.2 m~∞ 6 mm: 2.8 m~∞ 8 mm: 4.4 m~∞
Focal Length & Field of View:
2.8 mm, Horizontal Field of View: 108°, Vertical Field of View: 59°, Diagonal Field of View: 127° 4 mm, Horizontal Field of View: 87°, Vertical Field of View: 46°, Diagonal Field of View: 105° 6 mm, Horizontal Field of View: 54°, Vertical Field of View: 29°, Diagonal Field of View: 63° 8 mm, Horizontal Field of View: 41°, Vertical Field of View: 23°, Diagonal Field of View: 48° 12 mm, Horizontal Field of View: 23°, Vertical Field of View: 13°, Diagonal Field of View: 27°
Fill Light
Lighting Compensation Distance:
Infrared light extends up to 50 m, while white light reaches up to 30 m.
Anti-Overexposure:
Support
Infrared wavelength range:
850 nm
Lighting Fixtures Type:
Default intelligent fill light, capable of switching to infrared fill light and white light fill light
Certification
Electrical Safety Protection:
IP66
General Specifications
Interlinking Method:
Upload to FTP, Upload Center, Email, Video, Screenshot
Universal Features:
Heartbeat, password protection, video masking, watermark technology
Restore Factory Settings:
Supports client or browser recovery
Operating and working temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Power Supply Method:
DC: 12V ± 25%, with reverse polarity protection. PoE: IEEE 802.3af, Class 3. *DWDV3 model does not support PoE.
Current and Power Consumption:
DC: 12V, 0.54A, Maximum Power Consumption: 6.5W PoE: IEEE 802.3af, Class 3, Maximum Power Consumption: 7.5W *The DWDV3 model does not support PoE.
Power Interface Type:
Ø5.5mm round hole
Product Dimensions:
2.8mm focal length model: 182.8 × 92.7 × 87.6mm; Other focal length models: 189.4 × 92.7 × 87.6mm
Packaging Dimensions:
235 × 120 × 125 mm
Equipment Weight:
DWDV3 model: 580 g, WDV3 model: 595 g
Net Weight with Packaging:
DWDV3 model: 782 g, WDV3 model: 807 g
