• Maximum resolution up to 2560 × 1440@25 fps, capable of outputting real-time images at this resolution
• Utilizes high-efficiency array infrared lamps with a long service life; infrared beam can reach up to 10 meters in distance.
• Obstacle Detection: Equipped with an integrated ToF sensor, it can effectively detect the behavior of obstructed cameras. The maximum detection angle of the camera is 25°, with a default detection distance of 30 cm.
• Supports 1-way alarm input, 1-way alarm output, with a maximum alarm output of DC57V, 2A
• Built-in MicroSD/MicroSDHC/MicroSDXC slot, supports up to 512 GB
• 1 built-in microphone, 1 built-in speaker, supports two-way voice communication
• Meets IK08 riot design, high reliability

Video

Master Stream Frame Rate Resolution:

50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 720）

Sub-code stream frame rate resolution:

50 Hz：25 fps（704 × 576，640 × 480）

Video Compression Standards:

Main Stream: H.265/H.264; Sub Streams: H.265/H.264/MJPEG

Video Compression Bitrate:

32 Kbps~8 Mbps

H.264 Encoding Type:

baseLine Profile/Main Profile/High Profile

H.265 Encoding Type:

Main Profile

Smart264 Encoding:

Main stream support

Smart265 Encoding:

Primary Stream Supported

Bit Rate Control

Set bit rate, variable bit rate

ROI：

Supports setting one fixed area for the main stream code.

Event

Alarm Triggered:

Alarm Input, Anomaly, ToF Obstruction Alarm

Audio

Audio Compression Standards:

G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Audio Compression Bitrate:

64 Kbps（G.711ulaw/G.711alaw）/16 Kbps（G.722.1）/16 Kbps（G.726）/32~192 Kbps（MP2L2）/8~320 Kbps（MP3）/16~64 Kbps（AAC-LC）

Audio Sampling Rate:

8 kHz/16 kHz/32 kHz/48 kHz

Audio Environmental Noise Filtering

Support

Network Transmission

Network Protocol:

TCP/IP，ICMP，HTTP，HTTPS，FTP，DHCP，DNS，DDNS，RTP，RTSP，RTCP，NTP，UPnP，SMTP，IGMP，802.1X，QoS，IPv6，UDP，Bonjour，SSL/TLS，PPPoE，SNMP，WebSocket，WebSockets

Simultaneous preview paths:

Up to 6 channels

Interface Protocol (API):

Open Network Video Interface, ISAPI, SDK, ISUP (5.0), GB28181 (2022)

User Management:

Up to 32 users with three-tiered user permission management: Admin, Operator, and Regular User

Network Storage:

Supports NAS (supports NFS, SMB/CIFS), offline local recording storage and resuming transmission after network interruption, compatible with Hikvision's Black Card for SD card encryption and status monitoring

Client:

iVMS-4200, Hikvision Interconnect

Browser:

Preview with Plugin: IE10, IE11; Preview with Local Service: Chrome 57.0+, Firefox 52.0+, Edge 89+


Image Settings:

Mirror, video masking, saturation, brightness, contrast, sharpness, AGC, white balance are adjustable via client or browser.

Day/Night Switch Mode

Day and night, automatic and timed switching

Image Enhancement:

Backlight compensation, strong light suppression, 3D digital noise reduction, fog penetration

Wide Dynamic Range

120 dB

Interface

Internet:

1 RJ45 10/100 Mbps Auto-Negotiating Ethernet Port

SD card expansion:

Built-in MicroSD/MicroSDHC/MicroSDXC slot, supporting up to 512 GB

Built-in microphone:

Supports 1 built-in microphone

Built-in speaker:

Supports 1 built-in speaker

Alarm:

1 input, 1 output; Alarm output: Relay, max support DC 60V, 2A, output supports normally open (COM-NO) / normally closed (COM-NC) wiring

Reset:

Support

Camera

Sensor Type:

1/3" Progressive Scan CMOS

Minimum Luminance:

Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR

Maximum Image Size:

2560 × 1440

Shutter:

1 s~1/100,000 s

Day/Night Switch Mode

Electronic color-to-black conversion

Adjustable Angle:

Horizontal: -15° ~ 15°, Vertical: 0° ~ 75°

Lens

Focal Length & Field of View

2 mm, Horizontal Field of View: 128°, Vertical Field of View: 75°, Diagonal Field of View: 147°; 2.8 mm, Horizontal Field of View: 104°, Vertical Field of View: 57°, Diagonal Field of View: 122°; 4 mm, Horizontal Field of View: 84°, Vertical Field of View: 45°, Diagonal Field of View: 100°

Lens Size Interface:

M12

Maximum Aperture Number:

F1.6

Bulb Replacement

Lighting Fixtures Type:

Infrared light

Fill Light Distance:

Infrared light extends up to 10 meters.

Infrared wavelength range:

850 nm

Certification

Protection:

IK08

Standard Specifications

Linkage Method:

Upload FTP/SD card/NAS, upload center, email, video recording, screenshot, alarm output, audio alarm, voice announcement, flash alarm

Product Dimensions:

Installation of adapter plate: Ø120 × 77mm; Without adapter plate: Ø110 × 67mm

Packaging Size:

145 × 145 × 128 mm

Equipment Weight:

240 g

Net Weight with Packaging:

456 g

Startup and operating temperature and humidity:

-10 °C to 40 °C, humidity less than 95% (non-condensing)

Universal Features:

Heartbeat, password protection, watermark technology, IP address filtering, pixel calculator

Restore Factory Settings

Supports RESET button, client or browser restores

Current and Power Consumption:

DC: 12 V, 0.58 A, Maximum Power Consumption: 7 W PoE: IEEE 802.3af, Class 3, Maximum Power Consumption: 8 W

Power Supply Method:

DC: 12V ± 25%, reverse polarity protection supported; PoE: IEEE 802.3af, Class 3

Power Interface Type:

Ø5.5 mm round connector *Please provide your own DC 12 V, Ø5.5 mm round connector power adapter

Flashlight:

Support

AI Open Platform

Model Specifications:

1. Supports storage for 1 model package, which includes 2 types of object detection: electric vehicles, and shoulder-head. 2. Default rule: electric scooters enter the elevator, and headcount is taken.

Task Type:

Support video tasks (detection)

Algorithm Type:

Inspection: Regional Target Anomaly Status Detection, Cross-line Target Detection, Cross-line Target Statistics, Regional Target Count Statistics, Comprehensive Analysis Rules, Combination Rules

Rule Configuration:

Supports up to 4 rule configurations
