• Maximum resolution up to 2304 × 1296 @ 20 fps, capable of outputting real-time images at this resolution
• Backlight compensation supported, strong light suppression, 3D digital noise reduction, digital wide dynamic range, adaptable to various environments
• Supports Hikvision Interconnect Access
Support low bit rate mode
• Supports dual illumination with white light/IR, with IR light reaching up to 30m and white light up to 30m
• Supports LTE-TDD/LTE-FDD 4G wireless network transmission
• 1 built-in microphone, 1 built-in speaker, supports two-way voice communication
• Supports up to 512 GB of local storage via MicroSD/MicroSDHC/MicroSDXC cards
• Built-in dual SIM cards for China Telecom and China Unicom, automatically switching to the best network provider based on signal conditions
• Meets IP66 dust and water resistance design, high reliability
Video
Maximum Resolution:
2304 × 1296
Main Stream Frame Rate Resolution:
50 Hz：20 fps（2304 × 1296，1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：20 fps（768 × 432）
Video Compression Standard:
Main Stream: H.265; Sub Stream: H.265
Video Compression Bitrate:
32 Kpbs~2 Mbps
H.264 Encoding Type:
Main Profile
H.265 Encoding Type:
Main Profile
Bitrate Control:
Set bit rate, variable bit rate
SVC：
Support
ROI：
Support setting one fixed area for each stream code
Event
Routine Event:
Motion Detection (Supports Human and Vehicle Detection), Anomaly
Linkage Method:
Upload Center, Video Recording, Audio Alarm
Audio
Audio Compression Standards:
G.711/AAC-LC
Audio Compression Bitrate:
64 Kbps（G.711ulaw/G.711alaw）/16~64 Kbps（AAC-LC）
Audio Sampling Rate:
16 kHz
Environmental Noise Filtering:
Supported
Network Transmission
Network Protocol:
TCP/IP，DNS，IGMP，IPv4，IPv6，UDP，ICMP,，RTP
Interface Protocol (API):
Open Network Video Interface, ISAPI, SDK, GB28181, ISUP 5.0, Foscam Cloud
Client:
Hikvision Interconnect APP
Browser:
No-plugin Preview: Plug-in free live view - Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+ Local Service: Local service - Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Settings:
Brightness, White Balance, Saturation, Sharpness, Contrast
Day/Night Switch Mode
Day and night, automatic and timed switching
Wide Dynamic Range
Digital Wide Dynamic Range
Image Enhancement:
Backlight compensation, strong light suppression, 3D digital noise reduction
Shutter:
1/1 s~ 1/100,000 s
Interface
Audio:
1 built-in microphone, 1 built-in speaker
SD card expansion:
Built-in MicroSD/MicroSDHC/MicroSDXC slot, supports up to 512 GB
Reset:
Supported
Internet:
1 RJ45 10/100 Mbps Auto-negotiating Ethernet Port
Camera
Sensor Type:
1/2.7" Progressive Scan CMOS
Minimum Illuminance:
0.01 Lux
Day and night toggle mode:
ICR Infrared Filter
Lens
Focal Length & Field of View:
4mm, Horizontal Field of View: 83.2°, Vertical Field of View: 43.8°, Diagonal Field of View: 102.8°; 6mm, Horizontal Field of View: 52.6°, Vertical Field of View: 30°, Diagonal Field of View: 60.6°
Maximum Aperture Number:
F2.0
Lens Interface Size:
M12
Light Compensation
Fill Light Distance:
Infrared light reaches up to 30 meters, as does white light.
Infrared wavelength range:
850 nm
Anti-overexposure to fill light
Supports on/off for anti-backlight overexposure, with auto and manual options available when enabled. Manual control allows adjusting the brightness of the light source based on distance levels.
Lighting Type:
Toggleable between white light and infrared light
Mobile Communication Parameters
SIM Card Type:
Built-in telecom and Unicom cards
Frequency Band:
LTE-TDD：Band 34/38/39/40/41 LTE-FDD：Band 1/3/5/8
Standard:
LTE-TDD/LTE-FDD
Certification
Protection:
IP66
General Specifications
Storage temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Startup and operating temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Power Supply Method:
DC: 12V ± 25%, with reverse polarity protection supported
Current and Power Consumption:
DC: 12V, 0.66A, Max Power Consumption: 8W
Power Interface Type:
Ø5.5 mm round hole
Dimensions:
171.7 × 83.4 × 80.7 mm
Packaging dimensions:
235 × 120 × 125 mm
Weight:
410 g
Net Weight with Packaging:
530 g
System Management
Restore Factory Settings
Supports RESET button, client or browser resets
