• Maximum resolution up to 1920 × 1080 @ 25 fps, capable of outputting real-time images at this resolution
• Smart Detection: Supports boundary detection, area intrusion detection
• Backlight compensation, strong light suppression, 3D digital noise reduction, 120 dB wide dynamic range, suitable for various environments
• Built-in 1 microphone
• Supports soft light fill, with a maximum照射 distance of up to 30 m
• Compliant with IP67 dust and water resistance design, high reliability
Video
Maximum Image Size:
1920 × 1080
Main Stream Frame Rate Resolution:
50 Hz：25 fps（1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：25 fps（640 × 480，640 × 360）
Video Compression Standards:
Main Stream: H.265/H.264, supports Super Smart Coding; Sub Stream: H.265/H.264/MJPEG
Video Compression Bit Rate:
32 Kbps~8 Mbps
H.264 Encoding Type:
baseLine Profile/Main Profile/High Profile
H.265 Encoding Type:
Main Profile
Bit Rate Control:
Fixed bit rate, variable bit rate
ROI：
Support for setting 1 fixed region for the main stream
Event
Alarm Trigger:
Motion Detection (Supports human/vehicle shape detection), Anomaly
Audio
Audio Environmental Noise Filtering:
Support
Audio Sampling Rate:
8 kHz/16 kHz
Audio Compression Standards:
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
Audio Compression Bitrate:
64 Kbps（G.711ulaw/G.711alaw）/16 Kbps（G.722.1）/16 Kbps（G.726）/32~160 Kbps（MP2L2）/16~64 Kbps（AAC-LC）/8~160 Kbps（MP3）
Network Transmission
Simultaneous preview options:
Up to 6 channels
User Management:
Up to 32 users with 3-tiered user permission management: Administrator, Operator, and Regular User
Client:
iVMS-4200
Browser:
Use plugin-free preview: Chrome 91+, Firefox 88+, Edge 91+, Safari 13+ Use local service preview: Chrome 91+, Firefox 88+, Edge 91+
Interface Protocol (API):
Open-type network video interface, ISAPI, SDK, GB28181
Network Protocol:
TCP/IP，ICMP，HTTP，FTP，DHCP，DNS，RTP，RTSP，RTCP，NTP，SMTP，IGMP，QoS，UDP，Bonjour，SSL/TLS，HTTPS，DDNS，UPnP，802.1X，IPv6，IPv4
Day/Night Switch Mode
Day and night, automatic and timed switch
Image Enhancement:
Backlight compensation, strong light suppression, 3D digital noise reduction
Image Settings:
Mirror, saturation, brightness, contrast, sharpness, AGC, white balance adjustable via client or browser.
Interface
Audio:
1 built-in microphone
Internet:
1 RJ45 10/100 M Auto-sensing Ethernet Port
Camera
Sensor Type:
1/2.7" Progressive Scan CMOS
Minimum Illuminance:
Color: 0.0005 Lux
Shutter:
1 s~1/100,000 s
Wide Dynamic Range
120 dB
Lens
Lens Size Interface:
2.8/4/6 mm：M12 8 mm：M16
Aperture Type:
Fixed Aperture
Maximum Aperture Number:
F1.0
Depth of Field Range:
2.8 mm：1.5 m~∞ 4 mm：2.1 m~∞ 6 mm：4.6 m~∞ 8 mm：6.4 m~∞
Focal Length & Field of View:
2.8 mm, Horizontal Field of View: 106°, Vertical Field of View: 57°, Diagonal Field of View: 127° 4 mm, Horizontal Field of View: 84°, Vertical Field of View: 45°, Diagonal Field of View: 99° 6 mm, Horizontal Field of View: 55°, Vertical Field of View: 30°, Diagonal Field of View: 63° 8 mm, Horizontal Field of View: 42°, Vertical Field of View: 23°, Diagonal Field of View: 49°
Fill Light
Fill Light Distance:
Up to 30 m
Anti-overexposure protection:
Support
Lighting Type:
Soft Light Bulb
Certification
Electrical Safety Protection:
IP67
Standard Specifications
Leverage Mode:
Upload to FTP, Upload Center, Email, Video Recording, Screenshot
Universal Features:
Heartbeat, password protection, watermark technology, pixel calculator, video overlay
Restore Factory Settings
Supports client or browser recovery
Operating and Working Temperature and Humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Power Supply Method:
DC: 12V ± 25%, with reverse polarity protection; PoE: IEEE 802.3af, CLASS 3; *The DWDV3 model does not support PoE.
Current and Power Consumption:
DC: 12V, 0.54A, Max Power Consumption: 6.5W PoE: IEEE 802.3af, CLASS 2, Max Power Consumption: 8W *The DWDV3 model does not support PoE.
Power Interface Type:
Ø5.5 mm round hole
Product Dimensions:
2.8mm focal length model: 182.8 × 92.7 × 87.6mm; Other focal length models: 189.4 × 92.7 × 87.6mm
Packaging Dimensions:
235 × 120 × 125 mm
Equipment Weight:
620 g
Net Weight with Packaging:
760 g
Professional intelligence
Smart Alert:
Area intrusion detection, boundary crossing detection, entry area detection, exit area detection (supports human and vehicle detection)
