• Maximum resolution up to 2304 x 1296 @ 25 fps, capable of outputting real-time images at this resolution
• Backlight compensation supported, strong light suppression, 3D digital noise reduction, digital wide dynamic range
• Supports motion detection (including human shape detection) and anomaly detection
• Supports intelligent fill light, enabling color recording of alarm events; capable of switching between white light fill light and infrared fill light modes.
• 1 built-in microphone
• Meets IP67 dust and water resistance design, high reliability
Video
Maximum Resolution:
2304 × 1296
Main Stream Frame Rate Resolution:
50 Hz：25 fps（2304 × 1296，1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：25 fps（640 × 480，640 × 360）
Video Compression Standard:
Main Stream: H.265/H.264; Sub Stream: H.265/H.264
Video Compression Bitrate:
32 Kbps~8 Mbps
H.264 Encoding Type:
baseline Profile/Main Profile/High Profile
H.265 Encoding Type:
Main Profile
Bit rate control:
Set fixed coding rate, variable coding rate
ROI：
Not supported
Audio
Audio Compression Standards:
G.711alaw/AAC-LC
Audio Compression Bitrate:
64 Kbps（G.711alaw）/16~64 Kbps（AAC-LC）
Audio Sampling Rate:
8 kHz/16 kHz
Audio Environmental Noise Filtering:
Support
Network Transmission
Network Protocol:
TCP/IP，ICMP，HTTP，DHCP，DNS，RTP，RTSP，RTCP，NTP，IGMP，QoS，UDP
Simultaneous preview options:
Up to 6 channels
Interface Protocol (API):
Open-type network video interface, ISAPI, SDK, GB28181
User Management:
Up to 32 users, with 3-tier user permission management: Admin, Operator, and General User
Client:
iVMS-4200
Browser:
Use Local Service Preview: Chrome 57.0+, Firefox 52.0+, Edge 89+
smartIR：
Support
Image Settings:
Mirror, saturation, brightness, contrast, sharpness, AGC, white balance adjustable via client or browser
Day/Night Transition Mode
Day and night, automatic and timed switching
Image Enhancement:
Backlight compensation, bright light suppression, 3D digital noise reduction
Wide Dynamic Range
Digital Wide Dynamic Range
Interface
Internet:
1 RJ45 10/100 M Auto-sensing Ethernet Port
Audio:
1 built-in microphone
Camera
Sensor Type:
1/2.7" Progressive Scan CMOS
Minimum Illuminance:
Color: 0.01 Lux
Shutter:
1/3 s~1/100,000 s
Day and night toggle mode:
ICR Infrared Filter Sheet
Lens
Focal Length & Field of View
4 mm: Horizontal field of view: 86°, Vertical field of view: 45°, Diagonal field of view: 103° 6 mm: Horizontal field of view: 53°, Vertical field of view: 30°, Diagonal field of view: 61° 8 mm: Horizontal field of view: 42°, Vertical field of view: 23°, Diagonal field of view: 49° 12 mm: Horizontal field of view: 25°, Vertical field of view: 14°, Diagonal field of view: 29°
Lens Interface Size:
M12
Maximum Aperture Number:
F2.0
Fill Light
Tungsten Halogen Bulb, LED Bulb
Smart lighting with switchable white light and infrared light
Lighting Compensation Distance:
Infrared light reaches up to 50m, while white light extends to 30m.
Anti-overexposure to supplementary lighting
Supported
Infrared wavelength range:
850 nm
Certification
Protection:
IP67
Standard Specifications
Leverage Method:
Upload Center
Product Dimensions:
87.1 × 83.7 × 171.7 mm
Packaging Size:
216 × 121 × 118 mm
Equipment Weight:
360 g
Net Weight with Packaging:
543 g
Storage temperature and humidity:
-30 °C to 60 °C, humidity less than 95% (non-condensing)
Startup and operating temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Universal Features:
Heartbeat, password protection, watermark technology
Restore to factory settings:
Supports client or browser recovery
Current and Power Consumption:
Non-PoE models: DC: 12V, 0.42A, Max Power Consumption: 5W PoE models: DC: 12V, 0.42A, Max Power Consumption: 5W PoE: IEEE802.3af, CLASS 3, Max Power Consumption: 6.5W
Power Supply Method:
Non-PoE models: DC: 12V ± 25%, Reverse polarity protection supported PoE models: DC: 12V ± 25%, Reverse polarity protection supported PoE: IEEE 802.3af, Class 3
Power Interface Type:
Ø5.5mm round hole
