• Maximum resolution up to 3840 × 2160 @ 20 fps
• Backlight compensation supported, strong light suppression, 3D digital noise reduction, 120 dB wide dynamic range, adaptable to various environments
• Supports Smart Detection: Boundary Detection, Area Intrusion Detection
• Supports low bitrate, low latency, ROI (Region of Interest) enhanced encoding; compatible with Smart265 codec; capable of adapting bitrate allocation based on scenario requirements, effectively reducing storage costs.
• Supports MicroSD/MicroSDHC/MicroSDXC cards, up to 256 GB local storage
• 1 built-in microphone
• Supports dual illumination with white light/infrared, infrared range up to 50m, white light range up to 30m
• Compliant with IP66 dust and water resistance, high reliability
Video
Maximum Image Size:
3840 × 2160
Main Stream Frame Rate Resolution:
50 Hz：20 fps（3840 × 2160，3200 × 1800，2688 × 1520，1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：20 fps（1280 × 720，640 × 480，640 × 360）
Video Compression Standards:
Main Stream: H.265/H.264; Sub Stream: H.265/H.264/MJPEG
Video Compression Bitrate:
32 Kbps~16 Mbps
H.264 Encoding Type:
baseLine Profile/Main Profile/High Profile
H.265 Encoding Type:
Main Profile
Smart264 Encoding:
Main stream support
Smart265 Encoding:
Main stream support
Bit Rate Control:
Fixed coding rate, variable coding rate
SVC：
Supported
ROI：
Supports setting one fixed area for the main stream code
Event
Alarm Triggered:
Motion Detection, Obstruction Alarm, Anomaly
Smart Event:
Area intrusion detection, boundary detection
Audio
Audio Environmental Noise Filtering:
Support
Audio Sampling Rate:
8 kHz/16 kHz
Audio Compression Standards:
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC/MP3
Audio Compression Bitrate:
64 Kbps（G.711 ulaw/G.711 alaw）/16 Kbps（G.722.1）/16 Kbps（G.726）/32~160 Kbps（MP2L2）/16~64 Kbps（AAC）/8~160 kbps（MP3）
Network Transmission
Client:
iVMS-4200
Simultaneous preview options:
Up to 6 channels
Interface Protocol (API):
Open Network Video Interface, ISAPI, SDK, GB28181 (2016)
Network Protocol:
TCP/IP，ICMP，HTTP，HTTPS，FTP，DHCP，DNS，DDNS，RTP，RTSP，NTP，UPnP，SMTP，IGMP，802.1X，QoS，IPv6，UDP，Bonjour，SSL/TLS
User Management:
Up to 32 users, featuring a three-tiered user permission management system: Admin, Operator, and Regular User
Network Storage:
Supports NAS (supports NFS, SMB/CIFS), supports MicroSD/MicroSDHC/MicroSDXC cards (up to 256 GB), offline local recording and resume transfer, compatible with Hikvision Black Card for SD card encryption and status monitoring.
Browser:
Preview with Plugin: IE10, IE11; Preview with Local Service: Chrome 57.0+, Firefox 52.0+, Safari 12+
Day/Night Transition Mode
Day and night, automatic and timed switching
Image Enhancement:
Backlight compensation, strong light suppression, 3D digital noise reduction
Image Settings:
Mirror, video masking, saturation, brightness, contrast, sharpness, AGC, white balance adjustable via client or browser
Interface
Internet:
1 RJ45 10/100 M Auto-negotiating Ethernet Port
SD card expansion:
Built-in MicroSD/MicroSDHC/MicroSDXC slot, supports up to 256 GB
Audio:
1 Line In, 2-core terminal, Max Input Amplitude: 3.3 Vpp, Input Impedance: 4.7 kΩ, Interface Type: Unbalanced 1 Line Out, 2-core terminal, Max Output Amplitude: 3.3 Vpp, Output Impedance: 100 Ω, Interface Type: Unbalanced 1 Built-in Microphone
Alarm:
1 input channel, 1 output channel (alarm output supports max DC 12V, 30mA)
Reset:
Support
Power Output:
DC12V, 100mA, recommended for microphone power supply
Camera
Sensor Type:
1/1.8" Progressive Scan CMOS
Minimum Illuminance:
Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with Light
Shutter:
1/3 s~1/100,000 s
Wide Dynamic Range
120 dB
Day/Night Switch Mode
ICR Infrared Filter
Lens
Focal Length & Field of View
2.8 mm: Horizontal field of view: 102.2°, Vertical field of view: 55.1°, Diagonal field of view: 120.2°; 4 mm: Horizontal field of view: 79°, Vertical field of view: 43.3°, Diagonal field of view: 92°; 6 mm: Horizontal field of view: 50.8°, Vertical field of view: 27.6°, Diagonal field of view: 59.2°; 8 mm: Horizontal field of view: 37.7°, Vertical field of view: 21°, Diagonal field of view: 43.5°; 12 mm: Horizontal field of view: 24°, Vertical field of view: 13.7°, Diagonal field of view: 27.3°
Lens size and interface:
M12
Maximum Aperture Number:
F1.6
Fill Light
Lighting Type:
Infrared, white light
Lighting Compensation Distance:
Infrared light reaches up to 50 m, while white light extends to 30 m.
Anti-overexposure protection:
Supported
Infrared wavelength range:
850 nm
Certification
Protection:
IP66
Standard Specifications
Product Dimensions:
92.8 × 93.4 × 181.3 mm
Packaging Dimensions:
235 × 120 × 125 mm
Equipment Weight:
810 g
Net Weight with Packaging:
1025 g
Operating and Working Temperature and Humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Leverage Method:
Upload FTP/SD card/NAS, upload center, email, video recording, screenshot, alarm output
Current and Power Consumption:
DC: 12 V, 0.84 A, Max Power Consumption: 10.0 W PoE: 802.3af, 36 V~57 V, 0.35 A ~ 0.22 A, Max Power Consumption: 12.5 W
Power Supply Method:
DC: 12V ± 25%, Reverse polarity protection supported; PoE: 802.3af, Class 3
Power Interface Type:
5.5 mm round hole
Universal Features:
Heartbeat, password protection, watermark, IP address filtering, pixel calculator
Restore to Factory Settings:
Support client or browser recovery
