• Maximum resolution up to 2560 × 1440 @ 25 fps, real-time images can be outputted at this resolution
• Supports SmartIR to prevent infrared overexposure at night
• Backlight compensation, strong light suppression, 3D digital noise reduction, digital wide dynamic range
• Supports human detection
• Supports open network video interface, ISAPI, SDK, GB28181 protocol
• Smart illumination, supporting warm light/IR dual illumination; IR light can reach up to 50 m, while white light can reach up to 30 m.
• 1 built-in microphone
• Meets IP67 dust and water resistance design, high reliability
Video
Maximum Resolution:
2560 × 1440
Master stream frame rate resolution:
50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：25 fps（768 × 432，640 × 480，640 × 360）
Video Compression Standards:
Main Stream: H.265, supports Super Smart Coding; Sub Stream: H.265
Video Compression Bitrate:
32 Kbps~8 Mbps
H.265 Encoding Type:
Main Profile
Bit Rate Control:
Set bit rate, variable bit rate
SVC：
Support
Event
Routine Event:
Motion Detection (Supports Human Shape Detection), Anomaly
Audio
Audio Compression Standards:
G.711alaw/AAC-LC
Audio Compression Bit Rate:
64 Kbps（G.71alaw）/16~64 Kbps（AAC-LC）
Audio Sampling Rate:
8 kHz/16 kHz
Audio Environmental Noise Filtering:
Supported
Network Transmission
Network Protocol:
TCP/IP，ICMP，HTTP，DHCP，DNS，RTP，RTSP，RTCP，NTP，QoS，IPv4，UDP
Simultaneous preview options:
Up to 6 lanes
Interface Protocol (API):
OpenType Network Video Interface, ISAPI, SDK, GB28181
User Management:
Up to 32 users, with 3-tiered user permission management: Administrator, Operator, and Regular User
Client:
iVMS-4200
Browser:
Use local service preview: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
smartIR：
Supported
Image Settings:
Saturation, brightness, contrast, sharpness, AGC, white balance are adjustable via the client or browser.
Day/Night Switch Mode
Day and night, automatic and timed switching
Image Enhancement:
Backlight compensation, strong light suppression, 3D digital noise reduction
Interface
Internet:
1 RJ45 10/100 M Auto-Negotiating Ethernet Port
Audio:
1 built-in microphone
Camera
Sensor Type:
1/2.7" Progressive Scan CMOS
Minimum Luminance:
Color: 0.005 Lux
Shutter:
1/3 s~1/100,000 s
Wide Dynamic Range
Digital Wide Dynamic Range
Day-and-night mode switching
ICR Infrared Filter Sheet
Lens
Focal Length & Field of View:
4 mm: Horizontal field of view: 70°, Vertical field of view: 35°, Diagonal field of view: 85° 6 mm: Horizontal field of view: 46°, Vertical field of view: 24°, Diagonal field of view: 54° 8 mm: Horizontal field of view: 43°, Vertical field of view: 24°, Diagonal field of view: 50° 12 mm: Horizontal field of view: 27°, Vertical field of view: 15°, Diagonal field of view: 31°
Lens Mount Size:
M12
Maximum Aperture Number:
F2.0
Fill Light
Tungsten Halogen Light Bulbs
Smart lighting with switchable white light and infrared light
Lighting Compensation Distance:
Infrared light reaches up to 50 m, warm light up to 30 m
Anti-overexposure protection:
Support
Infrared wavelength range:
850 nm
Certification
Protection:
IP67
General specifications
Interlock method:
Upload Center
Product Dimensions:
108.1 × 111.4 × 216.7 mm
Packaging Dimensions:
272 × 134 × 140 mm
Equipment Weight:
700 g
Net Weight with Packaging:
980 g
Storage Temperature and Humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Startup and operating temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Universal Functions:
Heartbeat, Mirroring, Password Protection, Watermark Technology
Restore Factory Settings:
Supports client or browser recovery
Current and Power Consumption:
DC: 12 V, 0.54 A, Max Power Consumption: 6.5 W PoE: IEEE 802.3af, Class 3, Max Power Consumption: 8 W *The D-LA model does not support PoE
Power Supply Method:
DC: 12 V ± 25%, reverse polarity protection supported; PoE: IEEE 802.3af, Class 3 *Model D-LA does not support PoE
Power Interface Type:
Ø5.5 mm round hole
