• Maximum resolution up to 2560 × 1440 @ 25 fps, real-time images can be outputted at this resolution
• Supports SmartIR to prevent infrared overexposure at night
• Backlight compensation supported, strong light suppression, 3D digital noise reduction, digital wide dynamic range
• Supports human detection
• Supports open network video interface, ISAPI, SDK, GB28181 protocol
• Smart Re-lighting, supports warm light/infra-red dual re-lighting; infra-red light can reach up to 50m, while white light can reach up to 30m.
• 1 built-in microphone
• Compliant with IP67 dust and water-resistant design, high reliability
Video
Maximum Resolution:
2560 × 1440
Main Stream Frame Rate Resolution:
50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 720）
Sub-code stream frame rate resolution:
50 Hz：25 fps（768 × 432，640 × 480，640 × 360）
Video Compression Standards:
Main Stream: H.265, Supports Super Smart Encoding; Sub Stream: H.265
Video Compression Bitrate:
32 Kbps~8 Mbps
H.265 Encoding Type:
Main Profile
Bit Rate Control:
Set bit rate, variable bit rate
SVC：
Support
Event
Routine Event:
Motion Detection (Supports Human Detection), Anomaly
Audio
Audio Compression Standards:
G.711alaw/AAC-LC
Audio Compression Bitrate:
64 Kbps（G.71alaw）/16~64 Kbps（AAC-LC）
Audio Sampling Rate:
8 kHz/16 kHz
Audio Environmental Noise Filtering:
Supported
Network Transmission
Network Protocol:
TCP/IP，ICMP，HTTP，DHCP，DNS，RTP，RTSP，RTCP，NTP，QoS，IPv4，UDP
Simultaneous preview routes:
Up to 6 channels
Interface Protocol (API):
Open-type Network Video Interface, ISAPI, SDK, GB28181
User Management:
Up to 32 users with 3-tiered user permission management: Administrator, Operator, and Regular User
Client:
iVMS-4200
Browser:
Use Local Service Preview: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
smartIR：
Support
Image Settings:
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable via the client or browser.
Day/Night Transition Mode
Day and night, automatic and timed switching
Image Enhancement:
Backlight compensation, bright light suppression, 3D digital noise reduction
Interface
Internet:
1 RJ45 10/100 Mbps Auto-sensing Ethernet Port
Audio:
1 built-in microphone
Camera
Sensor Type:
1/2.7" Progressive Scan CMOS
Minimum Illuminance:
Color: 0.005 Lux
Shutter:
1/3 s~1/100,000 s
Wide Dynamic Range
Digital Wide Dynamic Range
Day/Night Switch Mode
ICR Infrared Filter Plates
Lens
Focal Length & Field of View:
4 mm: Horizontal field of view: 70°, Vertical field of view: 35°, Diagonal field of view: 85°; 6 mm: Horizontal field of view: 46°, Vertical field of view: 24°, Diagonal field of view: 54°; 8 mm: Horizontal field of view: 43°, Vertical field of view: 24°, Diagonal field of view: 50°; 12 mm: Horizontal field of view: 27°, Vertical field of view: 15°, Diagonal field of view: 31°
Lens Mount Size:
M12
Maximum Aperture Number:
F2.0
Fill Light
Lighting Fixtures Type:
Smart lighting with switchable white light and infrared light
Fill Light Distance:
Infrared light reaches up to 50 m, warm light up to 30 m
Anti-overexposure protection
Support
Infrared wavelength range:
850 nm
Certification
Protection:
IP67
General Specifications
Leverage Method:
Upload Center
Product Dimensions:
108.1 × 111.4 × 216.7 mm
Packaging Dimensions:
272 × 134 × 140 mm
Equipment Weight:
700 g
Net Weight with Packaging:
980 g
Storage Temperature and Humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Startup and operating temperature and humidity:
-30°C to 60°C, humidity less than 95% (non-condensing)
Universal Features:
Heartbeat, mirroring, password protection, watermark technology
Restore to Factory Settings
Supports client or browser recovery
Current and Power Consumption:
DC: 12V, 0.54A, Max Power Consumption: 6.5W PoE: IEEE 802.3af, Class 3, Max Power Consumption: 8W *The D-LA model does not support PoE.
Power Supply Method:
DC: 12V ± 25%, with reverse polarity protection; PoE: IEEE 802.3af, Class 3 *The D-LA model does not support PoE.
Power Interface Type:
5.5 mm round hole
