| Key Technical Specifications | |||||||
| Model and Specifications | CZ2X2 | CZ3X3 | CZ4X4 | CZ5X5 | CZ6X6 | CZ8X8 | |
| Effective travel of beam (mm) | 2000 | 3000 | 4000 | 5000 | 6000 | 8000 | |
| Effective Stroke of Beam (mm) | 2000 | 3000 | 4000 | 5000 | 6000 | 8000 | |
| Track Form (mm) | V-Groove Track | Rectangular track | |||||
| Maximum Beam Height (mm) | 2210 | 3360 | 4365 | 5415 | 6460 | 8720 | |
| Minimum Beam Height (mm) | 210 | 360 | 365 | 415 | 460 | 720 | |
| Carriage to rail height (mm) | 306 | 407 | |||||
| Lifting Speed (mm/min) | 1000 | ||||||
| Tension speed (mm/min) | 120-1200 | 100-1000 | |||||
| Trolley travel speed (mm/min) | 2000 | 800 | |||||
| Internal gauge (mm) | 1000 | 1500 | 1750 | 2000 | 2000 | 2230 | |
| Pole Rotation | Angle (°) | ±180° | |||||
| Speed (r/min) | 0.5 | 0.37 | 0.14 | 0.14 | |||
