• Maximum resolution up to 3840 × 2160 @ 15 fps, capable of outputting real-time images at this resolution
• Supports digital wide dynamic range, backlight compensation, strong light suppression, 3D digital noise reduction, adaptable to various environments
• Dual illumination with white light/IR light, white light up to 30m, IR light up to 30m
• 2 built-in microphones, 1 built-in speaker, supports 8m two-way voice intercom

Basic Parameters

Sensor Type:

1/2.7″ Progressive Scan CMOS

Minimum Luminance:

Color: 0.005 Lux

Lens

Focal Length:

Fixed focal length

Field of View:

4 mm, Horizontal field of view: 85.7°, Vertical field of view: 46.3°, Diagonal field of view: 102.3°

Maximum Aperture Number:

F2.0

Tripod

Pre-set points:

300 units

Horizontal Range:

0°~340°

Vertical Range:

0°~80°

Horizontal Speed:

4~40°/s

Vertical speed:

4~20°/s

Video

Maximum Resolution:

3840 × 2160

Master Stream Frame Rate Resolution:

50 Hz：15 fps（3840 × 2160， 2560 × 1440，1920 × 1080，1280 × 960，1280 × 720） 60 Hz：15 fps（3840 × 2160， 2560 × 1440，1920 × 1080，1280 × 960，1280 × 720）

Sub-code stream frame rate resolution:

50 Hz：15 fps（640 × 360，352 × 288） 60 Hz：15 fps（640 × 360，352 × 240）

Video Compression Standard:

Main Stream: H.265; Sub Stream: H.265

Video Compression Bitrate:

32 Kbps~8 Mbps

H.264 Encoding Type:

baseLine Profile/Main Profile/High Profile

H.265 Encoding Type:

Main Profile

Audio

Audio Compression Standards:

G.711/AAC-LC

Audio Compression Bit Rate:

64 Kbps（G.711）/16~64 Kbps（AAC-LC）

Audio Sampling Rate:

16 kHz

Environmental Noise Filtration:

Dual-mic noise reduction

Interface

Audio:

2 built-in microphones, 1 built-in speaker

Network Interface:

RJ45 network port, auto-sensing 10 M/100 M network data

SD card expansion:

Not supported

Reset:

Not supported

Fill Light

T8 Fluorescent Tube Light

Dual illumination support for infrared and white light, with intelligent lighting adjustment

Lighting Distance:

White light extends up to 30 m, infrared light up to 30 m

Anti-overexposure protection:

Support

Infrared wavelength range:

850 nm

General Specifications

Operating Temperature and Humidity:

Turn on grow light: -30℃ ~ 40℃, humidity below 95% (no condensation); Turn off grow light: -30℃ ~ 50℃, humidity below 95% (no condensation).

Storage Humidity:

-30°C to 50°C, humidity less than 95% (non-condensing)

Environmental Usage Instructions:

1. Do not use the equipment in environments with vibration or impact, such as on vehicles, trains, ships, port cranes, and large mining machinery, etc. 2. Avoid using the equipment in areas with severe corrosion, strong acids, high salt content, and alkali, such as offshore islands, platforms, ships, chemical industries, fumigation, coastal areas (within 5 km), and other special corrosive environments. 3. Do not operate the equipment in strong electromagnetic interference environments, such as the main transmission direction of broadcast tower antennas, switchgear areas of power substations, near power transmission lines of the power grid, track pantographs, radar, medical nuclear magnetic resonance, and near antennas of 4G/5G/FM base stations. 4. Do not use the equipment in extremely hot, cold, dusty, or long-term high humidity conditions; refer to the working temperature and humidity requirements.

Current and Power Consumption:

DC: 12 V, 0.75 A, Max Power Consumption: 9 W; PoE: IEEE 802.3af, Class 3, Max Power Consumption: 10.5 W

Dimensions:

Product Dimensions: 145.7 mm x 110.8 mm x 145.5 mm; Packaging Dimensions: 185 mm x 145 mm x 198 mm

Weight:

Equipment Weight: 500 g, Package Weight: 780 g

Certification

Protection:

IP65, Waterproof against heavy rain


Image Enhancement:

Backlight compensation, 3D digital noise reduction, strong light suppression

Wide Dynamic Range

Digital Wide Dynamic Range

Image Settings:

Contrast, brightness, saturation, white balance, sharpness

Event

Routine Event:

Motion Detection (Supports human and vehicle detection), Anomaly

Interconnection Method:

Upload Center, Audio Alarm

Agreement

Network Protocol:

TCP/IP，UPnP，RTP，ICMP，802.1X，DHCP，RTS，QoS，RTCP，HTTPS，IGMP，HTTP，IPv4，IPv6，FTP，UDP，DNS，NTP，SSL/TLS

Interface Protocol:

ISAPI, Hikvision SDK, GB/T28181-2022 protocol, ISUP 5.0, Open Network Video Interface

Linked Follow

System

Additional Features:

Password protection, video masking, watermark technology
