• Supports up to 1920 × 1080@30 fps high-definition video output
• With built-in stand, easy installation
• Supports white light alarm function
• Supports the smart265 efficient compression algorithm, capable of significantly saving storage space
• Extremely low illumination, 0.005Lux/F1.5 (color), 0.001Lux/F1.5 (black & white), 0 Lux with IR
• 4x optical zoom, 16x digital zoom
• Utilizes an efficient infrared array with low power consumption, projecting a maximum distance of up to 50 meters.
• Supports intelligent detection functions such as regional intrusion detection, boundary detection, and motion detection
• Supports offline continuation upload to ensure video recording is not lost, and works with Smart NVR for secondary intelligent search, analysis, and condensed playback of event recordings.
• Supports ultra-wide dynamic range of 120 dB, 3D digital noise reduction, strong light suppression, SmartIR
• Supports 350° horizontal rotation, 0°-90° vertical direction
• Supports scheduled screenshot and event-triggered screenshot functions
• Supports regional exposure and regional focus features
• Support Center Mirroring Function
• Built-in omnidirectional microphone, with support for 1 audio input and 1 audio output
• Built-in high-decibel speaker for two-way voice communication without external audio equipment
• Supports 4G (Mobile, Unicom, Telecom) network transmission, compatible with 3G (Mobile, Unicom, Telecom)
• Integrated NANO SIM card slot with a removable 4G IoT card
• Supports up to 256GB Micro SD/Micro SDHC/Micro SDXC card storage
• Supports Hikvision SDK, Open Network Video Interface, ISAPI, GB/T28181, Ehome Protocol, and Fluke Access
• IP66; 6000V lightning protection, surge protection, and spike protection, meets GB/T17626.5 Level 4 standard

Basic Parameters

Sensor Type:

1/2.8＂ progressive scan CMOS

Minimum Luminance:

Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 Lux with IR

Shutter:

1/1-1/30,000s

Focus Mode:

Semi-automatic; Manual; Automatic

Day/Night Switch Mode

Automatic ICR Color to Black Conversion

Slow shutter speed

Support

Wide Dynamic Range

120dB Ultra-Wide Dynamic Range

Strong Light Suppression:

Support

3D Noise Reduction

Support

Regional Exposure:

Support

Regional Focus:

Support

Image Parameter Switch

Support

Digital Zoom:

16x

Optical Zoom:

4x

Privacy Shield

Up to 24 pieces, quadrilateral area, supports multiple colors

Signal-to-Noise Ratio:

≥52dB

Lens

Focal Length:

2.8-12mm, 4x optical

Optical Zoom Speed:

Approximately 2.0 seconds

Field of View:

Horizontal: 100.5-32.7 (wide-angle-telescopic); Vertical: 52.8-18.4 (wide-angle-telescopic); Diagonal: 120.3-37.5 (wide-angle-telescopic)

Maximum Aperture Number:

F1.5

Tripod

Pre-set Point Video Freeze

Supported

Watchdog Function:

Pre-set Points/Cruise Scan

Azimuth information display:

Support

Horizontal Range:

350°

Vertical Range:

0°-90°

Horizontal Speed:

Horizontal keying speed: 0.1°-60°/s, adjustable; Horizontal preset point speed: 60°/s

Vertical Speed:

Vertical keying speed: 0.1°-50°/s, adjustable; vertical preset point speed: 50°/s

Magnification Ratio:

Support

Number of preset points:

300 units

Cruise Scan

8 pieces, each with the option to add 32 preset points

Power-down Memory

Support

3D Positioning:

Supported

Scheduled Task:

Pre-set Point; Camera Restart; Camera Calibration; Auxiliary Output; Cruise Scan

Video

Video Compression Bitrate:

32 kbps~16384 kbps

H.265：

Main Profile

Maximum Image Size:

1920 × 1080

Stream Type:

Main stream; Substream

Main Stream Frame Rate Resolution:

50Hz:25fps(1920×1080,1280×960,1280×720) 60Hz:30fps(1920×1080,1280×960,1280×720)

Sub-code stream frame rate resolution:

50Hz:25fps(704×576,640×480,352×288);60Hz:30fps(704×480,640×480,352×240)

Video Compression Standard:

H.265;H.264;MJPEG

H.264：

baseline Profile;Main Profile;High Profile

Smart 264：

Support

Smart 265：

Supported

SVC：

Support

ROI：

Supported

Audio

Audio Compression Standards:

G.711alaw;G.711ulaw;G.722.1;G.726;MP2L2;AAC;PCM

Intelligent

Smart Event:

Audio Anomaly Detection, Face Detection, Area Infiltration Detection, Boundary Crossing Detection, Entry Area Detection, Exit Area Detection, Object Left Detection, Object Pick-up Detection

Smart Recording:

Offline Resumption; Smart Post-search

Smart Coding:

Smart265; Smart264; Low Bit Rate; ROI; SVC

Internet

Network Storage:

NAS (NFS，SMB/ CIFS), ANR

Supporting Protocols:

IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,DHCP,Bonjour,WebSocket/WebSockets

Interface Protocol:

Open API for software integration; ISAPI; Hikvision SDK; third-party management platform integration; GB/T28181 protocol; Ehome protocol; support for Dahua access; ISUP; open network video interface

Maximum number of flow paths:

20 lines

User Management:

32 units

Safety Management:

Authorized username and password; MAC address binding; HTTPS encryption; IEEE 802.1x network access control; IP address filtering

Client:

Supports iVMS-4200 client

Browser:

IE10-11, Chrome 57.0+, Firefox 52.0+, Safari 12+

Mobile Communication Parameters

Wireless Standard:

LTE-TDD/LTE-FDD

Wireless Frequency Band:

LTE-TDD：Band 34/38/39/40/41 LTE-FDD：Band 1/3/5/8

Interface

Power Output:

DC12V; Current less than 60mA

Network Interface:

RJ45 port; auto-sensing 10M/100M network data

SD card expansion:

Supports Micro SD/Micro SDHC/Micro SDXC cards, up to 256GB

Alarm Input:

1 Line Alarm Input

Alarm Output:

1-way alarm output

Audio Input:

1 audio input, audio peak: 2-2.4V[p-p], input impedance: 1 kΩ±10%

Audio Output:

1 audio output, linear level, impedance: 600Ω

Fill Light

Infrared Beam Distance:

50 meters

Alarm Light:

Support

General specifications

Universal Functions:

Mirroring, password protection, watermark technology, IP address filtering

Application Environment Instructions:

1. Do not operate the equipment in environments with vibration or shock, such as vehicles, high-speed trains, ships, port cranes, and large-scale mining machinery, etc. 2. Avoid using the equipment in highly corrosive, acidic, or saline-alkaline areas, including offshore islands, platforms, ships, chemical industries, fumigation, coastal areas within 5 kilometers, and other special corrosive environments. 3. Do not use the equipment in strong electromagnetic interference environments, such as the main transmission direction of broadcast tower antennas, substation closing zones, near power transmission lines, track power collectors, radar, medical nuclear magnetic resonance, and near antennas of 4G/5G/FM base stations. 4. Do not use the equipment in extreme hot or cold, dusty, or high humidity conditions for extended periods. Refer to the working temperature and humidity requirements.

Power Supply:

DC12V *Equipped with power adapter at factory

Current and Power Consumption:

16W max

Operating Temperature and Humidity:

-30°C to 65°C; humidity less than 90%

Restore Factory Settings:

Support

Material:

PC+ADC12

Dimensions:

179.3×120.5×182mm

Weight:

1.125Kg

Certification

Protection:

IP66; 6000V surge, surge protection, and transient protection, compliant with GB/T17626.5 Grade 4 standard


Image Settings:

Saturation, Brightness, Contrast, Sharpness

Day/Night Conversion Method:

Day/Night, Auto/Timer Switch

Through the fog:

Support

Event

Common Event:

Motion Detection, Obstruction Alarm, Alarm Input, Alarm Output, Anomalies (Hard Drive Full, Hard Drive Error, Network Disconnection, IP Address Conflict, Unauthorized Access), Flashing Alarm Light Output, Audio Alarm Output

Alarm linkage:

Support alarm联动preset points/cruise scan/SD card recording/alarm output/email/upload center/upload FTP/NAS/flashing alarm/sound alarm
