Nanjing Purified Water Filtration System - Quankun Provides RO Reverse Osmosis Purified Water System

Reverse Osmosis Equipment Technical Features:

First and second stage reverse osmosis recovery rates are adjustable; the first stage reverse osmosis recovery rate is 60% to 65%, and the second stage reverse osmosis recovery rate is 70%; both first and second stage reverse osmosis systems have recycle pipes, and the reverse osmosis equipment is equipped with chemical cleaning and sterilization devices.

1. The system utilizes full automatic control (manual control is also available), allowing for automatic backwash and regeneration programs to be set during operation.

2. The secondary reverse osmosis membrane utilizes positively charged anti-fouling reverse osmosis membranes to ensure long-term stable operation of the reverse osmosis equipment.

3. Both the stage reverse osmosis and stage reverse osmosis equipment are equipped with online conductivity meters, allowing the conductivity of the produced water to be monitored at any time; a low-pressure protection switch is installed before the first-stage reverse osmosis, and both low-pressure and high-pressure protection switches are set before the second-stage reverse osmosis.

4. All pretreatment units are equipped with original imported parts; the piping between pretreatment equipment is made of UPVC material. The pure water storage tank is equipped with a breathing filter, and the conveying pipes are fitted with an ultraviolet sterilizer and a microporous filter to ensure the purity of water meets hygiene standards.

5. The primary reverse osmosis pipeline is made of 304 stainless steel, while the secondary reverse osmosis uses 316L stainless steel. A pH adjustment device is installed between the primary and secondary reverse osmosis to ensure the conductivity of the produced water meets pharmacopoeial standards.

Equipment Features:

High water quality, stable water production.

Continuous uninterrupted water production, no downtime due to regeneration.

3. Modular production with full automatic control capability.

4. No need for acid and alkali regeneration; no wastewater discharge.

5. Acid and alkali-free regeneration equipment and chemical drug storage and transportation.

6. The equipment has a compact structure and occupies a small area.

7. Low operating and maintenance costs.

8. Easy operation, low labor intensity

Performance Advantages:

1. Continuously and stably produces high-quality pure water without downtime for resin regeneration.

2. Zero pollutant emissions, both environmentally friendly and eliminating the investment in waste liquid treatment.

3. The equipment features a compact structure, occupies minimal space, saving room, and also boasts energy-saving benefits.

4. Fully assembled units are ready for debugging upon factory completion, with minimal on-site work and easy training for new staff.

5. Routine maintenance, simple operation, and low labor intensity.

6. Desalination rate exceeds; efficiency is far superior to two-stage reverse osmosis and pure ion exchange.

 Nanjing Purified Water Filtration System - Quankun Provides RO Reverse Osmosis Purified Water System

Application Fields:

1. Power Plant Chemical Water Treatment

2. Ultra-pure water for electronics, semiconductor, and precision machinery industries

3. Food, beverage, and drinking water preparation

4. Compact Pure Water Station, Group Drinking Pure Water

5. Fine Chemicals, High-Tech Discipline Water

6. High-purity Water Production for Other Industries

7. Zhiyao Industrial Process Water

8. Desalination of seawater and brackish water.
