Applied

　The HF series cone-shaped mixer is a novel material mixer widely used in industries such as pharmaceuticals, chemicals, metallurgy, food, light industry, and feed. It can uniformly mix powders or granules, achieving a good mixing effect for the processed materials.

Principle

Material is loaded into a closed, frustum-shaped mixing drum. The axis of the hopper is at an angle to the axis of rotation. Different component materials undergo three-dimensional movement within the enclosed hopper, resulting in intense flipping and diffusion, achieving excellent mixing results.

Features

The complete machine features innovative design, compact structure, attractive appearance, mixing uniformity up to 99%, and a volume loading coefficient of 0.8.

Low turnover height, smooth operation, reliable performance, and easy operation.

The inner and outer walls of the drum are mirror-polished, ensuring no blind spots, easy discharge, easy cleaning, and no cross-contamination, meeting GMP requirements.

Technical Specifications
