BFKG-7.5 3P Explosion-proof Split Air Conditioner, manufactured and sold by Baiketeao Explosion-proof Air Conditioning Factory
Explosion-proof air conditioners are designed with explosion-proof features based on branded air conditioners, adhering to the requirements of the GB3836 series standards. They undergo special processing techniques and manufacturing methods for explosion-proof treatment.
◆Choose from various air conditioner brands as per customer requirements, such as Midea, Gree, Mitsubishi, etc.
The explosion-proof air conditioner pipeline connection is similar to that of a regular air conditioner. The electrical connection must strictly follow the installation requirements for explosion-proof electrical appliances. First, the power source should be introduced into the explosion-proof control box, and then separately introduced from the explosion-proof control box to the indoor unit and outdoor unit.
The explosion-proof control box is equipped with a power switch.
◆ Available for explosion-proof treatment of special air conditioning equipment on-site as per customer requirements. Examples include large-scale chilled water units, refrigeration units, central air conditioning systems, and air conditioning equipment with special installation forms. We will design and manufacture the solution, submit it for customer review, and upon request, can apply for on-site product explosion-proof performance testing by an explosion-proof testing center.
◆All explosion-proof air conditioners are supplied with a complete set of product technical documentation at the time of manufacture.InstallationUser Manual, users must strictly follow the instructions in the manual for installation and use.
◆Compressors: Utilizing renowned brands like Hitachi, Toshiba, Mitsubishi, Daikin, etc., with integrated design, self-cleaning evaporator feature, digital temperature display, large diameter, non-uniform airfoil, high airflow, and low noise.
The product features a compact structure, attractive and elegant design, and easy installation and maintenance.
◆ Steel pipe or cable wiring.
◆The entire unit employs internationally leading ultra-low-voltage technology for intrinsic safety circuit isolation. It is manufactured through special processes and explosion-proof treatment. The design and manufacturing of the product strictly adhere to national standards.
Section 1: Composition of Explosion-Proof Air Conditioners:
Explosion-proof air conditioners are not ordinary AC units; they are specialized electrical equipment designed for specific industries. These units offer both cooling and heating capabilities along with automatic defrosting functions. However, the components like compressors and fans in explosion-proof air conditioners undergo special explosion-proof treatments. The composition includes the intake and exhaust air outlets, drainage pipes, connecting pipes, and the outdoor unit. The outdoor unit is further made up of a compressor, exhaust fan, heat exchanger, and capillary tubes.
Section 2: Industry Applications for Explosion-Proof Air Conditioners:
Explosion-proof air conditioners are used in oil procurement sites, drilling platforms, chemical industries, oil depots, offshore platforms, refineries, coal mines, textile factories, toy factories, grain processing plants, oil depots, and gas warehouses, etc.
Section 3: Principle of Operation for Explosion-Proof Air Conditioners:
Explosion-proof air conditioners are primarily due to their inclusion of aluminum alloy explosion-proof materials. The honeycomb-like structure formed by the apertures in these layered materials divides the interior of the container into numerous "small compartments." These "small compartments" effectively inhibit the spread of flames, thereby providing excellent heat insulation and ensuring safety to a certain extent. Additionally, the honeycomb structure boasts a high surface efficiency per unit volume, offering excellent thermal conductivity. This allows for rapid absorption of the majority of heat released during combustion, significantly reducing the temperature (Tf) after the combustion reaction, lessening the degree of expansion of the reaction gases, and preventing a substantial increase in the container's pressure.
Service Warranty:
One, Quality Assurance:
1. The product division scope conforms to the quality standards set by the factory, department, and national standards.
2. Product quality is in compliance with the "Regulations on Product Quality Supervision of the People's Republic of China," which implements a three-package policy (repair, replacement, and refund).
3. For matters not within the supplier's responsibility, the buyer shall propose them, and both parties will negotiate a resolution.
Section II Supply Assurance:
1. Customers may place orders by phone, email, or fax, or personally pick up and purchase goods at the supplier's location.
2. Local bulk goods suppliers can deliver to the buyer's location and conduct acceptance and signing of documents.
3. Upon the buyer's request, the supplier shall24Respond and resolve within hours. For special circumstances, solutions will be negotiated between both parties.
Section 3: Returns and Exchange Policy:
1. All goods sold, if unused, undamaged, and in original packaging, can be negotiated for a return within one week of purchase.
2. If the sold goods indeed have quality issues, we are responsible for repairing, replacing, or refunding them within the specified time frame, as required by the Quality Law.
3. Items sold are non-refundable or exchangeable if damaged due to improper use or storage by the consumer. However, we can assist with repairs, with the consumer covering the costs.
4. If the sold goods meet the return conditions, in case of price adjustment, the increase will be refunded at the original price; the decrease will be refunded at the current day's price.
5. Special orders and processed goods are non-refundable and non-returnable.
