Particle size range

0.3μm,0.5μm,1μm,3μm,5μm,10μm

Laser Light Source

Laser Diode

Air Pump

Stable operation with energy-saving and environmental protection

Inspection Standards

JJF1190-2008，GB/T6167-2007

Relative Repeatability Error

Under the same measurement conditions, the repeatability of the continuous particle concentration measurements is less than 10%.

Particle size distribution error

0.5μm, 5μm particle size range distribution error ±10%

Particle concentration indication error

The particle counter is in normal operating condition after calibration, and the particle concentration reading error for the 0.5μm particle size range does not exceed ±20% FS.

Self-cleaning time

≤10min (three consecutive counts of zero within 10 minutes, with 95% confidence)

Sampling Time

User-defined (1-14400) seconds

Sampling Delay

User-defined (0-255) seconds

Sample frequency

1 to 9,999 times

Sample Point Count

1-999 points

Office Hours

6-hour continuous test time with a full charge

Data Memory Capacity

1 to 20,000 sets of measurement data, available for inquiry

Data Export Methods

USB flash drives and cables export

Audit Trail

Standard Configuration

Tier 3 Access Permissions

User parameter setting permission, inquiry permission, data export permission

Screen Display

7-inch IPS Smart Touch Screen

Printing Method

Embedded thermosensitive printing

Charging Adapter

Input: 100V～240V, 2.5A; Output: 16.8V, 5A

Charging Time

6H

Cleanliness Grade Determination Criteria

ISO 14644-1, GMP Dynamic, GMP Static

Work Environment

Work Environment: Temperature 0-40°C, Relative Humidity 10-90%, Non-Condensing pH

Storage Environment

Storage Environment: Temperature -10～50℃; Relative Humidity 0～90%; Non-condensing pH

Dimensions

Length 297 × Width 233 × Height 253 (mm)

Material

SUS304 Stainless Steel

Weight

7.0 KG (Battery life of 4H: 6KG)

Optional accessories

Humidity and Temperature Monitoring
