Product Description

Definition of a black body: An object that absorbs all external radiant energy and simultaneously radiates out all of its own energy.

The primary technical specifications of the blackbody include: the emissivity of the blackbody, the diameter of the blackbody aperture, temperature uniformity, and uncertainty in radiative temperature. Therefore, to ensure the quality of the blackbody, they are typically designed in segments according to temperature. The blackbody we commonly refer to is an artificial blackbody. The emissivity of the artificial blackbody is close to 1 but not equal to 1.

The bold function primarily generates standard radiation at certain temperatures. Therefore, it is mainly used in temperature measurement for calibrating various radiation thermometers, such as optical pyrometers, infrared thermometers, and infrared thermographic cameras.

The blackbody is mainly used in the industrial field for temperature measurement, with the main product being the blackbody furnace. Calibration and verification of radiation thermometers are typically done using the comparative method, which involves comparing the temperature reproduced by the standard instrument (usually a blackbody radiation source) with the temperature reproduced by the radiation thermometer under test, to determine its qualification or provide calibration results.

Standard blackbody as a standard radiation source, mainly used for calibrating radiation thermometers, infrared thermometers, and radiation temperature sensor detectors. Our company currently has advanced blackbody technology, offering a full range of blackbody series products with wide temperature ranges. The products are compact, lightweight, and easy to carry, suitable not only for calibration of radiation thermometers in laboratories of various metrological institutions but also for on-site calibration.

Product Applications

Planar blackbody radiation sources are infrared radiation working standards, widely used in process testing and identification tests during the development of infrared detectors. They can complete tests on parameters such as the uniformity of the photosensitive surface response of infrared focal plane devices, response curves, and dead pixel images. Additionally, as the core equipment of infrared imaging alignment devices, planar blackbody radiation sources, when paired with infrared collimating optical systems and infrared targets, can perform key technical indicator tests and performance evaluations for infrared imaging systems. They can meet the testing requirements for infrared imagers in newly developed infrared imaging guidance weapons in our country and can satisfy the testing needs of infrared thermography cameras widely used in industries such as medical, construction, security monitoring, and environmental detection.

Product Features

1. More portable and lightweight. Higher precision.

2. User-friendly interface with Chinese characters, touch operation, and elegant design.

3. One-touch temperature setting, easy to operate. Fast heating, temperature control.

4. Multiple language interfaces from various countries can be copied upon customer request, facilitating exports.

【Product Advantages】

1) Innovative design with an integrated furnace and temperature control instrument.

2) The heater and housing are insulated, utilizing special software for pressure-limited heating, eliminating the need for a high-power power transformer.

3) Utilizes automatic temperature control for quick, safe heating with excellent temperature stability.

4) Easy to use, compact, and lightweight, ideal for portability—perfect for both lab and on-site calibration tasks.

5) Large-area isothermal blackbody radiation surface with adjustable emissivity (adjustable between 0.95-1, with a default emissivity of 0.95 at factory)

6) Built-in multi-point independent temperature correction function for the screen.

7) Automatic Intelligent Adjustment: Equipped with advanced control algorithms featuring MH logic intelligent adjustment and parameter self-tuning functions.

8) Program control feature, with 10 different program setting interfaces pre-installed, one-touch operation for convenience and speed, meeting various user detection point requirements and enhancing detection efficiency.

9) Communication interface is customizable for RS232.

10) The equipment features memory function, allowing it to quickly restore to the previous setting state after a restart without the need for additional startup settings.
