This valve is equipped with corresponding electric or pneumatic actuators, compatible with various different brands and models of actuators. It receives ON-OFF or 4-20mA signals, performs PID regulation, directly alters the flow rate of the medium being adjusted, maintaining the controlled process parameters at the set value. The fluid passage is in a Z-shape, featuring responsive operation, minimal pressure drop loss, high allowable pressure difference, large flow capacity, wide adjustable range, simple wiring, high flow rate, compact size, and high regulation accuracy.

Operating Temperature: -60℃ ~ 250℃
