This valve is equipped with corresponding electric or pneumatic actuators, compatible with various brands and models of actuators. It receives ON-OFF or 4-20mA signals, performs PID control, directly altering the flow rate of the medium being adjusted, ensuring the controlled process parameters remain at the specified value. The fluid passage is Z-shaped, featuring responsive operation, minimal pressure drop loss, high allowable pressure difference, large flow capacity, wide adjustable range, simple wiring, high flow rate, compact size, and high regulation accuracy.

Operating Temperature: -60℃ ~ 250℃
