This valve is equipped with a corresponding electric or pneumatic actuator, compatible with various different brands and models of actuators. It receives 4~20mA signals, performs PID regulation, directly alters the flow rate of the medium being adjusted, maintaining the controlled process parameters at the specified value. The fluid passage is S-shaped, featuring sensitive operation, low pressure drop loss, high flow capacity, wide adjustable range, simple wiring, high flow rate, compact size, and high regulation accuracy.
Operating Temperature < 510°C
