Product Introduction:The VMQ series flash measurement instruments are primarily used for measuring flat dimensions, such as precision machined parts, stampings, sealing parts, ceramic substrates, mobile phone accessories, and other high-precision, large-volume products.
The accuracy of this measuring machine reaches the micron level, and surprisingly, it's extremely easy to operate, even for those not familiar with measurement procedures. The measuring software used by this machine, the DQ Instruments professional one-touch software, features a user-friendly interface, allowing operators to measure complex workpieces after just a few hours of use.
Key Features:
1. Auto-image registration feature; no need for workpiece positioning or fixtures; products can be placed freely, achieving automatic recognition and measurement; capable of identifying and measuring multiple workpieces simultaneously, and outputting results.
2. The image sensor features an imported high-definition 6MP CCD, paired with a GigE Gigabit Ethernet card (data rate: 1G/S), ensuring clear imaging and fine image quality.
3. Utilizing imported bilateral telecentric lenses, paired with parallel telecentric transmission light (transmission system), programmable four-zone annular shadowless incident light (incident light system), coaxial incident light, and low-angle shadowless incident light (optional light source), we ensure the authenticity, stability, and observability of the product images required for measurement. This results in measurement data that is very close to the true value, with highly stable repeated measurements, preventing operators from doubting the measurement results due to significant data discrepancies.
4. Instruments controlled by the Kuehne + Nagel technology can be directly paired with Kuehne + Nagel's intelligent software, making instrument lighting control, workbench movement control, and camera exposure control extremely simple and intuitive to operate.
5. The internal frame and workbench of the complete machine are made of aviation aluminum profiles, ensuring the stability of the instrument; the outer cover is made of ABS plastic shell, which is natural, non-toxic, and neat and aesthetically pleasing.
6. Utilizing professional-grade one-click measurement software with robust functionality and intuitive operation, enhanced by domestic software engineers' testing and adjustments for a more user-friendly experience; plus, we assure that we can modify the software according to the specific measurement requirements our clients propose.
