The most prominent feature of the model is the all-transparent, pressure-resistant casing, which is made using a special process.

This helical casing successfully resolves the two major contradictions of conventional helical casings, which cannot withstand pressure for simulation demonstrations and are inconvenient for teaching or experiments due to their metallic nature, thereby establishing a reputation as the leader among peers. Our company has manufactured this for North China Institute of Water Resources.

Graduate project "Reversible Model of Visualized Turbine Generator," known as "A First in China."

I. Basic Structure

Engine assembly (models made to a scale of 1:8 of the actual product)

Housing. Full transparent, integral pressure-resistant housing with special process seams, capable of preventing future adhesive separation and cracking.

The hassle-free solution, capable of withstanding over 20 meters of water head impact, and allowing observation of each component's operation from all angles.

Dynamic. Such as: fixed guide vanes with light colors, transparent or semi-transparent movable guide vanes, and turning vanes made of copper sheets.

Wheels, dark butterfly valves, etc., dimensions, shapes, positions, functions, operating conditions, and water flow status

The state is clear at a glance. Corrosion and moisture-resistant, strong and durable. In summary, this helix shell successfully addresses the conventional

Several contradictions arise due to the shell's inability to withstand pressure, making simulation demonstrations impossible, and the inconvenience of using metallic shells for teaching.

And are recognized as the industry leader.

Rim. The blades of the rim are formed by stamping copper sheets, with their size and shape proportionally reduced.

The bracket is tightly integrated with the upper and lower seats, forming an integral unit. It operates at high speeds under hydraulic impacts.

Stainless steel shaft connects with the generator section, providing both strength and corrosion resistance.

Activity guide vanes and regulators. Streamlined guide vanes are available in transparent and opaque versions, manufactured in batches.

Uniform in appearance, offering flexible adjustment and a tight closure. The regulating mechanism is highly realistic, available in both manual and electric versions.

Two options are available for your selection, and they can also be used together.

Generator. The main shaft of the generator is equipped with a small generator for actual power generation demonstration; lifting and lowering mechanism

Made of transparent material, viewable directly; stator and rotor仿实体制作，with added color, square

Detailed explanation; there are 60 stator parts. The sections can be easily disassembled at any time for teaching purposes; adjustable speed, electric lights, electricity

The indicator is clearly marked. The entire structure is supported by a stainless steel frame, facilitating observation.

Attached facilities. Sections such as the factory's structure, operating cranes, transparent tail water pipes, and door opening machines, etc., are all available.

Yes; Organic seat. Wooden planks are used to form a frame, with nine plywood boards added on top, then a new material is applied, with stainless steel corners wrapped around.

Overall, it is smooth and durable, with corrosion and moisture resistance.

2. Recirculating Water Supply (Water Head Height to be Determined as Per Customer Requirement)

Recirculating water supply, with three tanks: an upper tank, a lower tank, and a tail tank; interconnected by supply water

PVC pipes are interconnected, with large-diameter submersible pumps used for lifting water levels.

Three water tanks are all sized after theoretical calculations and verified through experiments. The overhead tank (rep)

The upstream water level) and the downstream water tank) are made of new materials and reinforced with angle steel externally, which can prevent deformation.

Form cracking; the upper water tank is supported by a tower-type bracket (removable) welded with angle steel, internally fitted with valves for opening and closing.

Operate on the ground, tail water tank (representing downstream water level) constructed from thick transparent organic sheets, reinforced with stainless steel frames.

Harmonious and aesthetically pleasing.

II. Water Conduction Test

This product is a large-scale dynamic simulation model, capable of actual water flow experiments, demonstrating the gold process as it is in real life.

The hydroelectric generating unit's power generation process is fully in line. During the experiment, simply press the power button to first fill the upper water tank.

Turn the water tank valve to start the power generation demonstration. Students can directly observe the various components of the water turbine generator set.

Shapes and dynamics can be observed, where the fork can be seen to display the state of water flow through its various parts. Because it can truly emit

Electricity comes with high reliability. A powerful assistant for teaching and a reliable instrument for experimental research.
