Nanjing Low-temperature Evaporation Wastewater Treatment Equipment, Standard Discharge, Oil Contaminated Wastewater Treatment Equipment

Low-temperature evaporators, online waste liquid concentration evaporators are an environmentally friendly and energy-saving equipment that can purify waste cutting fluids, emulsions, grinding fluids, and other metalworking fluids. Operating at low temperatures of 33°C, these evaporators achieve high efficiency with a reuse rate of over 85%, saving some concentrate for outsourcing processing and reducing the company's production and operation costs.

Product Specifications:

Name: Wastewater Processor (Low Temperature Evaporation Equipment) Outflow Water Quality (COD): Around 300 Electricity Consumption: 90~180 kWh/m³ Treatment Capacity: 200-2000 L/D Daily Output: 200-2000 L/D Hourly Output: 10-100 L/H Applicable Objects: Soluble liquids Properties: A wastewater/effluent evaporation and concentration treatment equipment.

Product Features:

1. Fully or semi-automatic equipment can be designed, requiring no dedicated supervision, with easy operation and excellent wastewater treatment results; 2. Saves investment and operating costs for the enterprise; 3. The system is easy to operate and intuitive to learn; 4. Equipment performance is stable, allows for continuous operation, and occupies minimal space.

Equipment Features:

1. Fully automatic equipment can be designed, requiring no dedicated supervision.

2. Easy to operate, with excellent wastewater treatment results (semi-automatic operation can also be designed).

3. Low operating noise, no impact on equipment. Environment.

4. Purify waste liquid and recycle reclaimed water to reduce production costs.

5. Physically low-temperature operation, no consumables required, energy-efficient and cost-saving.

Equipment Advantages:

1. Economic benefits: Can significantly reduce the cost of outsourcing wastewater treatment, with the potential to cut industrial wastewater treatment outsourcing costs by up to 90%.

2. Reduce COD evaporation and lower processing quality. The water level is high.

3. When using conventional MVR evaporator equipment, the operator detected a COD of 2000, while the COD content of the waste liquid low-temperature evaporation system is less than 300, meeting the HJ-T399-2007 standard. Manual operation has evolved into a fully automated and mechanized workforce.

4. The equipment operates smoothly and can handle large volumes of wastewater.

Nanjing Low Temperature Evaporation Waste Water Treatment Equipment, Standard Discharge, Oil Contaminated Waste Water Treatment Equipment

The Principle of Low-Temperature Evaporation Waste Water Treatment Equipment:

Low-temperature evaporation wastewater treatment equipment purifies and recycles water by utilizing the evaporation and condensation processes, which is achieved by lowering the temperature of the wastewater. The core principle involves introducing the wastewater into an evaporator, where it is heated by a heat source, causing the water in the wastewater to evaporate into steam. Subsequently, the steam enters a condenser, where it is condensed back into liquid water by a cooling medium, thereby purifying and recycling the wastewater.
