Boiler Capacity:0.5 to 40 steam tons

Steam pressure range:0.7MPa-1.0MPa-1.2MPa-1.6MPa-2.0MPa (Pressure customizable)

Design thermal efficiency≥95% (about 10% more energy-efficient than similar products)

Applicable Fuel:Liquefied gas, diesel, light oil, heavy oil, coal gas, etc.

Application Range:Chemistry, plastics, rubber, construction, forestry, pharmaceutical industry distillation

Product Description:The WNS series gas-fired steam boiler is a mature product of our company, featuring optimized configuration and advanced technical specifications. The WNS horizontal full-automatic oil-fired steam boiler is equipped with a high-performance industrial burner and has significantly upgraded smoke box covers. It features movable front and rear smoke box covers for easy maintenance. The WNS horizontal full-automatic oil-fired steam boiler truly achieves clean combustion, low emissions, convenient operation, and sufficient output.

Boiler Performance Description:

Boiler Performance

WNS series gas-fired steam boilers feature the latest technology, a wet-back bottom corrugated furnace tube structure, and a three-pass flue gas design, offering strong load adaptability and efficient combustion. They achieve a thermal efficiency of over 95%, and their flue gas emissions meet environmental requirements. The compact structure is easy to install and the high level of automation ensures safe operation. They are widely used in industrial and mining enterprises, institutions, schools, hospitals, hotels, and other organizations, and are highly favored by users.

2. Boiler Features:

(1) Utilizes a wet-back structure with a lower furnace chamber, corrugated furnace tube, and a three-pass smoke design, meeting national environmental emission standards.

(2) The furnace膛 is equipped with a corrugated firebrick, significantly enhancing the heating surface and strength.

(3) Reasonably structured and compact, with strong load adaptability, efficient combustion, and high thermal efficiency.

(4) Large heating surface area, quick升温 and pressure increase, easy to operate.

(5) Complete with safety accessories, the main body is absolutely safe and operates economically.

(6) Equipped with high-quality, high-performance burners for stable combustion.

High level of automation, labor-saving.

(8) Boilers are compact in size, lightweight, occupy minimal floor space, and reduce infrastructure investment.
