YT-30CS Ultrasonic Humidifier
Model: YT-30CS
Brand: YingTeng
Power: 3000W
Power: 220V~50Hz
Aerosol Particles: <10 micrometers
Net Weight: 75 kg
Humidification Rate: 30 kg/h
Airflow: 950 m³/h
Mist outlet quantity: 2 x 160mm
Rated Input Current: 13.7A
Dimensions (mm): 725 x 910x550
Note: The above parameters are for reference only. Any changes will not be notified in advance; the physical unit shall prevail!
◎Principle of Operation: Ultrasonic Humidifier
The ultrasonic industrial humidifier utilizes electronic ultra-frequency oscillation (oscillation frequency of 17MHz) to produce a natural, floating mist by the high-frequency resonance of the atomizing plate, propelling water away from the surface. It generates 1-5 micron water particles floating in the air without the need for heating or chemicals, thereby increasing the relative humidity of the air.
Ultrasonic Humidifier Usage Conditions: Environmental Temperature: Normal operating temperature is 0-40℃; Water Source: Use clean, neutral tap water.
Features of Ultrasonic Humidifier:
※The ultrasonic humidifier features an integrated atomization module with replaceable chips, allowing for easy maintenance and on-site operation.
High-efficiency ultrasonic humidifier (nearly 100% humidity increase rate), strong humidification intensity, produces fine and even mist particles, quickly achieving the desired relative humidity.
The integrated atomizer core comes with an automatic water level protection device, which effectively ensures that the atomizer core stops working automatically when the water level is too low, without the need for additional equipment, thus saving costs.
Flexible and convenient operation, with full automatic humidity control for the ultrasonic humidifier.
Automatic humidity control with a renowned brand humidity sensor for high accuracy and rapid response. Once set, it operates continuously without the need for human supervision.
The ultrasonic humidifier features an aesthetically pleasing and generous design, is corrosion-resistant, and boasts a long lifespan.
The ultrasonic humidifier has undergone extensive testing and years of practical operation, featuring a compact structure and rational design. It operates silently and achieves high liquid atomization efficiency.
