YingTengDuct-type Explosion-proof Air Conditioning Unit

2-horsepower duct-type explosion-proof air conditioner

Model: BKF-50-Ex(F)

Brand: YingTeng

Cooling/Heating Capacity (W): 5000/5800

Rated Voltage (V): 220

Rated Frequency (Hz): 50

Rated Power (W): 1920

Recirculating Airflow m³/h: 820

Net Weight (Indoor/Outdoor): 34/55 kg

Dimensions: 920 mmx450x210

Explosion-proof marking: Ex db ib mb IIB T4 Gb

Manufacturer: Henan Tongteng Explosion-Proof Electrical Appliances Co., Ltd.

Note: The above technical specifications are for reference only, and the physical unit shall prevail.

The Yinteng explosion-proof air conditioner features the explosion-proof mark of Ex db ib mb IIB T4 Gb.

This series of products complies with the following standards:

GB/T 3836.1 - 2021 "Explosive Atmospheres - Part 1: Equipment - General Requirements"

GB/T 3836.2-2021 "Explosive Atmospheres - Part 2: Equipment protected by explosion-proof enclosures 'd'"

GB/T 3836.4-2021 "Explosive Atmospheres *Part 4: Equipment protected by intrinsic safety 'i'"

GB/T 3836.9-2021 "Explosive Atmospheres *Part 9: Equipment protected by "m" type enclosures"

GB/T 3836.15-2017 "Explosive Atmospheres *Part 15: Design, Selection, and Installation of Electrical Equipment"

Explosion-proof air conditioners can operate normally under the following environmental conditions:

a) Altitude not exceeding 2,000m

b) Suitable for environments with temperatures ranging from -7℃ to 43℃, free of corrosive gases.

c) There are explosive hazard areas formed by mixtures of flammable gases, vapors, and air from Groups II A, II B, and T1 to T4.

The "Yingteng" explosion-proof air conditioning series models have been processed with special explosion-proof technology and are widely applicable in flammable and explosive areas of Zones 1 and 2. They are suitable for research, oil, chemical, pharmaceutical, and power plant environments where IIA, IIB, T1-T4 group combustible gases and steam-air mixtures may form explosive hazards. Explosion-proof air conditioners are used in places with temperature requirements. The Yingteng explosion-proof air conditioners have passed inspections by the National Explosion-Proof Electrical Product Quality Supervision and Inspection Center and received explosion-proof certification and CCC certification. They feature an aesthetically pleasing design, reasonable structure, ease of installation and maintenance. The full range of explosion-proof air conditioners are equipped with brand compressors, microcomputer intelligent control, digital display, and offer low noise, stable performance, simple operation, and safety. They are highly favored in the market. (Customizable options include explosion-proof window-type air conditioners, explosion-proof duct-type air conditioners, explosion-proof ceiling-mounted air conditioners, explosion-proof fresh air air conditioners, explosion-proof marine air conditioners, explosion-proof corrosion-resistant air conditioners, explosion-proof high-temperature air conditioners, explosion-proof cold storage air conditioners, explosion-proof modular air conditioning units, and explosion-proof multi-split air conditioning units, etc.).
