Product Specifications
Brand: YingTeng
Model: BL-300(DM450L)
Door: Cross door
Total Volume (L): 450
Refrigeration Volume (L): 288 (2℃-8℃)
Temperature Change Chamber Volume (L): 22 (with three temperature settings: 4°C/0°C/-1°C)
Refrigeration Capacity (L): 150 (-15℃ ~ -25℃)
Rated Voltage: 220V/50Hz
Total Energy Consumption (kw·h/24h): 0.82 kw·h/24h
Energy Efficiency Rating: 1
Freezing Capacity (kg/12h): 7
Cooling Capacity (kg/12h): /
Noise db(A) 36
Climate Type: SN/N/ST/T
Product Dimensions (WxDxH) mm: 794*650*1900
Explosion-proof marking: Ex db ib II CT 4 Gb
Manufacturer: Henan Tongteng Explosion Proof Electrical Equipment Co., Ltd.
Note: The above technical specifications are for reference only; the actual product should be used as the standard.
Explosion-proof Refrigerator Types: Available in single-door vertical freezing and refrigeration, double-door vertical freezing and refrigeration, left-right door vertical freezing and refrigeration, horizontal freezing and refrigeration, single-door glass refrigerator, single-door glass cool cabinet, double-door glass refrigerator, double-door glass cool cabinet, triple-door glass refrigerator, triple-door glass cool cabinet, stainless steel double-door refrigerator-freezer, double-door dual-temperature explosion-proof refrigerator, dual-temperature double-door explosion-proof refrigerator, single-door single-temperature explosion-proof refrigerator, multi-temperature multi-door explosion-proof refrigerator, glass-door refrigerator explosion-proof refrigerator, horizontal explosion-proof refrigerator, horizontal dual-temperature explosion-proof refrigerator, stainless steel explosion-proof refrigerator, ultra-low temperature explosion-proof refrigerator, -22°C explosion-proof refrigerator with glass door, -25°C explosion-proof refrigerator, -40°C explosion-proof refrigerator, -60°C explosion-proof refrigerator, 86°C ultra-low temperature explosion-proof refrigerator, and various other specifications. Custom production according to customer requirements is also available.
The "YingTeng" explosion-proof refrigerator series has been processed with special explosion-proof technology, making it suitable for use in flammable and explosive areas in Zones 1 and 2. It is widely applicable in scientific research, oil, chemical, pharmaceutical, and power plant environments where IIA, IIB, T1-T4 groups of combustible gases and steam-air mixtures may form explosive hazards. Explosion-proof refrigerators are ideal for locations with temperature requirements. The YingTeng explosion-proof refrigerators have been inspected and certified by the National Quality Supervision and Inspection Center for Explosion-Proof Electrical Products, receiving both explosion-proof certification and CCC certification. They feature an aesthetically pleasing design, reasonable structure, and ease of installation and maintenance. The entire series uses brand-name compressors, microcomputer intelligent control, digital display, and boasts low noise, stable performance, simple operation, and safety. They are highly favored in the market.
YingTeng explosion-proof refrigerator conforms to standard
Explosion-proof Execution Standards: The explosion-proof refrigerator has been tested by the National Explosion-proof Electrical Product Quality Inspection and Testing Center and meets the following standards:
GB3836.1-2021 "Electrical Equipment for Explosive Gas Atmospheres - Part 1: General Requirements"
GB3836.2-2021 "Electrical Equipment for Explosive Gas Atmospheres - Part 2: Equipment with "d" Intrinsic Safety Protection"
GB3836.4-2021 "Electrical Equipment for Explosive Gas Atmospheres - Part 4: Equipment with "i" Protection"
GB3836.9-2021 "Electrical Equipment for Explosive Gas Atmospheres*Part 9: Equipment with 'm' Type of Encapsulation Protection"
GB3836.15-2017 "Electrical Equipment for Explosive Gas Atmospheres – Part 15: Design, Selection, and Installation of Electrical Installations"
YingTeng Explosion-Proof Refrigerator Product Features
Insulated glass design, excellent thermal performance, effective anti-fogging, and excellent display effect.
Super-thick foam layer, heat-insulating properties, highly efficient thick precision insulation layer, enhanced thermal insulation effect.
Swivel wheel design, easy and lightweight to move.
Branded compressors, featuring high-efficiency cooling, low noise, low power consumption, and stable performance; ◎Adjustable shelf layers, with customizable height for easy storage of items.
220V/110V, your choice.
Precision Computer Temperature Control System: Equipped with a precise temperature sensor inside the cabinet to maintain stable internal temperature; an intelligent control fan forced air circulation system to ensure uniform temperature distribution inside the cabinet.
Automatic Temperature Control: High-brightness digital display, temperature setting within the range of 2°C to 8°C, display accuracy of 0.1°C. Uses non-fluorine environmentally friendly refrigerant, international brand high-efficiency compressor, energy-saving and quiet.
Air-cooled high-efficiency condenser, finned evaporator, rapid refrigeration.
Optional sound and light alarm system: Features high-temperature, low-temperature, and sensor failure alarms, ensuring safer storage of items; equipped with a lock on the door to prevent unauthorized access.
Inten Explosion Proof Refrigerator - Application Range
Explosion-proof refrigerators are widely used in: oil, chemical industry, pharmaceuticals, aerospace, laboratories, storage, and other places. They are suitable for hazardous areas within zones 0 or 1 of explosive gas mixtures with II A, II B, II C classification and temperature group T4. The BL series industrial-grade explosion-proof refrigerators/freezers/coolers are explosion-proof refrigerators manufactured with integrated explosion-proof technology, meeting the requirements for industrial environment use and classified as IC.
