Product Specifications

BL-900 (BL1200L) Three-Door Single Temperature Explosion-Proof Refrigerator

Model: BL-900 (BL1200L)

Brand: YingTeng

Door Type: Single-Sided Three-Door

Climate Type: SN.N.ST

Total Effective Volume: 1300L

Rated Voltage: AC 220V

Rated Frequency: 50Hz

Rated Power: 425W

Temperature Range: 0°C ≤ T ≤ 10°C

Rated power consumption: 4.5 Kwh/24h

Noise: 40 dB(A)

Freezing Capacity: 8 kg/24h

Electrical Shock Protection Type: I

Dimensions: 1670×530×1440mm

Ex db IIB T4 Gb

Manufacturer: Henan Tongteng Explosion-Proof Electrical Equipment Co., Ltd.

Note: The above technical specifications are for reference only, and the actual product should be used as the standard.

Manufacturer: Henan Tongteng Explosion Proof Electrical Equipment Co., Ltd.

Note: The above technical specifications are for reference only, and the physical product should be taken as the standard.

Explosion-proof Refrigerator Types: Available in single-door upright freezing and refrigeration, double-door upright freezing and refrigeration, left-right door upright freezing and refrigeration, horizontal freezing and refrigeration, single-door glass refrigerators, single-door glass coolers, double-door glass refrigerators, double-door glass coolers, triple-door glass refrigerators, triple-door glass coolers, stainless steel double-door refrigeration-freezing units, double-door dual-temperature explosion-proof refrigerators, dual-door dual-temperature explosion-proof refrigerators, single-door single-temperature explosion-proof refrigerators, multi-temperature multi-door explosion-proof refrigerators, glass door refrigeration explosion-proof refrigerators, horizontal explosion-proof refrigerators, horizontal dual-temperature explosion-proof refrigerators, stainless steel explosion-proof refrigerators, ultra-low temperature explosion-proof refrigerators, -22°C glass door explosion-proof refrigerators, -25°C explosion-proof refrigerators, -40°C explosion-proof refrigerators, -60°C explosion-proof refrigerators, 86°C ultra-low temperature explosion-proof refrigerators, and various other specifications. Custom production according to customer requirements is also available.

The "Yingteng" explosion-proof refrigerator series has been processed with special explosion-proof technology, suitable for use in flammable and explosive areas in Zones 1 and 2. It is widely applicable in scientific research, oil, chemical, pharmaceutical, and power plant environments where IIA, IIB class T1-T4 combustible gases, steam, and air mixtures pose explosion hazards. These explosion-proof refrigerators are suitable for locations with temperature requirements. The Yingteng explosion-proof refrigerators have passed inspections by the National Supervision and Inspection Center for Quality of Explosion-Proof Electrical Products and have been issued explosion-proof certification and explosion-proof CCC certification. They feature an aesthetically pleasing design, reasonable structure, and ease of installation and maintenance. The entire series utilizes brand-name compressors, microcomputer intelligent control, digital display, and boasts low noise, stable performance, simple operation, and reliability, making them highly favored in the market.

YingTeng explosion-proof refrigerator conforms to the execution standard

Explosion-proof Execution Standards: The explosion-proof refrigerator has been tested by the National Explosion-proof Electrical Product Quality Inspection and Testing Center and meets the following standards:

GB 3836.1-2021 *1 Part: General Requirements for Electrical Equipment for Explosive Gas Atmospheres

GB3836.2-2021 Electrical Equipment for Explosive Gas Atmospheres Part 2: Equipment with "d" Type of Protection "Ex d"

GB3836.4-2021 "Electrical Equipment for Explosive Gas Atmospheres*Part 4: Equipment for Protection by Intrinsic Safety"

GB3836.9-2021 "Electrical Equipment for Explosive Gas Atmospheres - Part 9: Equipment with 'm' Type of Encapsulation Protection"

GB3836.15-2017 "Electrical Equipment for Explosive Gas Atmospheres*Part 15: Design, Selection, and Installation of Electrical Installations"

Inten Explosion-Proof Refrigerator Product Features

Insulated glass design with excellent thermal performance, effective anti-fogging, and great display effects.

Extra-thick foam layer with insulating properties, high-efficiency thick precision thermal insulation, enhanced thermal retention.

Swivel wheel design, easy and lightweight movement.

Branded compressors, high-efficiency cooling, low noise, low energy consumption, and stable performance; ◎Adjustable shelves, with customizable layer heights for convenient storage.

Choose from 220V or 110V.

Precision Computer Temperature Control System: Equipped with a precise temperature sensor inside the cabinet to maintain stable internal temperature; intelligent control fan forced air circulation system to ensure uniform internal temperature.

Automatic Temperature Control: High-brightness digital display, set any temperature within the range of 2°C to 8°C with a display accuracy of 0.1°C. Utilizes non-fluorine environmental-friendly refrigerant, international brand high-efficiency compressor, energy-saving and noiseless.

Air-cooled high-efficiency condenser, finned evaporator, rapid refrigeration.

Optional sound and light alarm system: Features high temperature, low temperature, sensor failure, and other sound and light alarm functions for enhanced safety of stored items; equipped with a lock on the door to prevent unauthorized opening.

YingTeng explosion-proof refrigerator application range

Explosion-proof refrigerators are widely used in: oil, chemical and petrochemical, pharmaceutical, aerospace, laboratory, storage, and other places. They are suitable for hazardous areas within zones 0 or 1 of explosive gas mixtures with II A, II B, II C classification and temperature group T4. The BL series industrial-grade explosion-proof refrigerators/freezers/coolers are explosion-proof refrigerators of IC classification, manufactured in accordance with industrial environmental usage requirements and integrated explosion-proof technology.
