AY-BTJ Steel Wire Rope Core Tape Peeling Machine, Conveyor Belt Skinning Machine, Laminated Tape Stripping Machine

Application:

Power plants, mining, steel mills, ports, petrochemical plantsAYThe BPJ series of peelers is designed for securing and cleaning the adhesive layer on the leading edge of the belt joint during preparation, which can be used in various situations and locations.

Large stripping area and high speed can significantly reduce labor intensity and shorten the time required for joints.

2. Lightweight for easy carrying and handling.

3. Stable operation.

Motor Power: 0.75 kW

Line Speed: 0.3 m/s

3. Strip Width: 200mm (Conveyor Belt & Steel Cord Conveyor Belt) 400mm (Standard Belt)

Usage Instructions:

1. Align the conveyor belt centerline as per standard methods, and then use a knife to score and separate the corresponding joint area, peeling off one layer.

2. Place the conveyor belt peeler in the proper position and secure it with steel wire ropes.

3. Power on.

4. Clamp the separated layer with a fixture, start the motor, and use a blade to score the剥离part at the appropriate location.

After peeling off one layer, repeat the above steps to peel off the second, third layers, etc.

Cautionary Notes:

1. Power connection must be performed by a qualified electrician.

2. Secure the peeler in use to prevent slippage.

Do not exceed the specified width during stripping.
