Stratified Head剥皮 Machine, Steel Wire Rope Core Conveyor Peel Machine, Explosion Proof Electric Stripping Machine

From the leather strap openingDirectly force the blade diagonally into the space between the two curtain fabrics, then maintain the blade tip at a 15° to 20° angle with the belt surface. On one hand, apply force to push the blade into the layers; on the other hand, move the blade horizontally, using the reciprocating vibration of the blade tip to separate the belt layers.

Including the housing and the micro-motor installed within it. An eccentric shaft is connected to the micro-motor's shaft, which is then connected to a slider. A blade is secured to the top of the slider with screws, and the stopper is fixed to the housing with screws.

The electric strip opener can be used to open strips from either the belt end or the middle. It is compact, lightweight, and easy to operate, making it convenient for on-site use. This electric strip opening blade is suitable for opening strips in belt splicing processes, particularly for rapid repairs of conveyer belts. The practical tool features a simple structure and high efficiency and safety, with the advantage of reducing laborious and inefficient manual operations.

Voltage:220V

Power:0.25-0.75KW

Dimensions:280×65×180（mm）
