Stripping Clamp for Belts, 1.5KW Layered Stripper Machine, Core Wire Rope Stripper Head Machine
| BPJ-3 General Conveyor Belt Peeling Machine Application Range: Separation of cover rubber with canvas, cover rubber with steel wire rope, and canvas between various fabric cores and steel wire rope cores conveyor belts; Technical Parameters of General Conveyor Belt Peeling Machine: 1. Power Supply, Voltage: 380V 50Hz 2. Power: 0.75Kw, 1.1Kw, 1.5Kw 3. Weight: 32KG, 41KG, 50KG 4. Application Range: EP, NN, cotton canvas, and various layered belt joints, general conveyor belts with widths of 650mm to 2200mm; Features of General Conveyor Belt Peeling Machine: 1. Large peeling area and fast speed, significantly reducing labor intensity and time required for joints; 2. Light weight, easy to carry and transport; 3. Stable operation. Usage of General Conveyor Belt Peeling Machine: 1. Align the conveyor belt according to standard methods, and use a knife to score and separate a layer at the corresponding joint; 2. Place the peeling machine at an appropriate location and secure it with a steel wire rope; 3. Connect the power supply; 4. Clamp the separated layer with a fixture, start the motor, and use a knife to score the peeling section at an appropriate location; 5. After peeling one layer, repeat the above steps to peel off the second, third, and subsequent layers; Precautions for Using General Conveyor Belt Peeling Machine: 1. Power connection should be handled by a professional electrician; 2. Secure the peeling machine during use to prevent sliding; 3. Do not exceed the specified width during peeling. |
