M3325 Dust Removal Sanding Machine, Electric Vacuum Sanding Machine, Twin Head Sanding Machine Driver
Grinding, deburring, and cleaning. Dust-removing grinding wheels are primarily used in industrial and mining enterprises for sharpening cutting tools, and can also be used for grinding, deburring, and cleaning of ordinary small parts.
2 Low environmental requirements.Dust-removing grinding wheel machineCan be used at altitudes not exceeding1,000 meters, with relative humidity of the surrounding air not exceeding 90% and the surrounding environmental temperature not exceeding 40℃.
High dust removal rate and safety. This machine employs bag dust removal, achieving an efficiency over 98% with dust concentration less than 10 mg/m³. Compliant with national labor and human resources and environmental health department safety regulations, it provides excellent vacuuming performance, improves the working environment, and protects operators from dust exposure.
4 For indoor use only. Dustless grinding wheels are not resistant to chemical corrosion and must not be used outdoors.
Section 2: Technical Specifications of the Grinding Wheel Machine
New model | MC3015 | MC3020 | MC3025 | MC3030 | MC3035 | MC3040 |
Power | 0.25 | 0.5 | 0.75 | 1.5 | 1.75 | 2.2 |
Frequency | 50 | 50 | 50 | 50 | 50 | 50 |
Current | 1.7 | 1.24 | 1.7 | 3.4 | 3.95 | 4.9 |
RPM | 2850 | 2850 | 2850 | 1420 | 1440 | 1430 |
Efficiency | 67 | 71 | 75 | 79 | 80 | 81 |
Section 3: Instructions for the Use of the Grinding Wheel Machine
The grinding wheel machine must be measured with a megohmmeter of over 500 volts before use, with an insulation resistance value of not less than 0.5 megohms.
2. Thoroughly inspect the grinding wheel before use to check for any damage or cracks due to transportation. Pay special attention to the absence of cracks in the grinding wheel. Gently tap with a wooden mallet; a clear, crisp sound indicates the item is in good condition.
3.Dust Removal Grinding Wheel MachineBefore use, manually rotate the shaft extension to check for smooth and easy movement, and closely listen for any rubbing noises.
4. The direction of rotation for grinding wheels and fans should match the direction indicator.
5. During operation, do not allow the workpiece to collide with the grinding wheel. Apply pressure gradually to prevent shock to the wheel, avoiding explosion and accidental incidents.
6. Grinding Wheel MachineProtective guard replacement, including grinding wheels除了拆解和维修之外，平时严格禁止拆卸以确保安全。
7. Use two medium-grit grinding wheels, where the difference in their wear diameter does not exceed 20%.
8. While in use, the grinding wheel machine should always produce normal sounds. If a scream, a buzzing noise, or other strange sounds occur, stop immediately to inspect the cause of the noise, and only resume use after the issue is resolved.
9. When the dust accumulates increasingly in the filter bags of the grinding wheel machine, it affects the wind suction capacity of the fan. Therefore, it is necessary to regularly open the front door, remove the dust bag, and empty the dust from inside the bag.
