· Suitable for grinding steel plates/Carbon steel/Alloy steel/Malleable Iron/Non-ferrous Metals/Copper components/Aluminum Components/Wood/Stone/Glass and other non-metallic materials。

· Shipyard, boiler factory, large steel plate welding factory, cast steel/Cast Iron/Casting copper factory grinding, deburring, and polishing machines.

· Time-saving.High efficiency. High-power aluminum shell motor, Protective Cover,Prevent sparks from flying out.

· Machine front features wheel grinding,The top cover can be opened for long workpiece grinding.

· The machine allows for adjustable grinding depth in both upward and downward directions, and grinding workpieces at different angles.

The grinding wheel machine's rotation direction must be correct, allowing the chips to fly away from the wheel downwards only.

After the grinding wheel machine is started, grinding should be performed only after the machine has rotated smoothly. If the machine exhibits significant vibration, it should be stopped and adjusted immediately.

The abrasive wheel machine bracket and abrasive wheel should maintain a distance of 3mm to prevent workpieces from piercing and causing accidents.

When grinding, stand on the side of the grinding wheel machine and avoid excessive force.

5 Select a grinding wheel that matches the spindle speed of the grinding machine according to the instructions provided.

6 New grinding wheels must have a factory certificate of conformity or inspection and test mark. Do not use the wheel if any defects such as quality, hardness, particle size, or cracks in appearance are found before installation.

When installing the grinding wheel, the clearance between the inner hole of the wheel and the main shaft should not be too tight. It should be adjusted according to the technical requirements for loose fit, generally controlled between 0.05 and 0.10 millimeters.
