Electric Dual-Station Polishing Machine, Low-Base Polishing Machine, Tip-Switchable Polishing Machine
Voltage: (3-phase power)380V——This is the specification for a 4kW two-speed polishing machine
Machine RPM(1st gear): 1430 rpm, Current: 7.4A, Power: 3.3 kW
Machine RPM(2 Gear): 2850 rpm Current: 8.6A Power: 4 kW
Frequency:50Hz
Polishing Machine Power: Available3KW, 4KW, 5.5KW options available
Two-speed operation: one gear for1430r/min，One grade for2850r/min
Grinding, deburring, and cleaning. Dust-removing grinding wheels are primarily used in industrial and mining enterprises for sharpening cutting tools, and can also be used for grinding, deburring, and cleaning of small parts.
2 Low environmental requirements.Dust-extraction type grinding wheel machineCan be used at altitudes of not more than1000 meters, surrounding air relative humidity not exceeding 90% High environmental temperature not exceeding40°C humid tropical region.
High dust removal efficiency The machine utilizes bag dust removal technology, achieving a dust removal efficiency of over 98% with dust concentration less than 10 mg/m³. Complies with the Ministry of Labor and Human Resources and the Ministry of Environmental Health of the country. Regulated excellent vacuuming performance Labor environment Operators are protected from dust exposure..
4 For indoor use only. Dustless grinding wheels are not resistant to chemical corrosion and should not be used outdoors.
Section 2. Technical Specifications of the Grinding Wheel Machine
New model | MC3015 | MC3020 | MC3025 | MC3030 | MC3035 | MC3040 |
Power | 0.25 | 0.5 | 0.75 | 1.5 | 1.75 | 2.2 |
Frequency | 50 | 50 | 50 | 50 | 50 | 50 |
Current | 1.7 | 1.24 | 1.7 | 3.4 | 3.95 | 4.9 |
RPM | 2850 | 2850 | 2850 | 1420 | 1440 | 1430 |
Efficiency | 67 | 71 | 75 | 79 | 80 | 81 |
Section 3: Sanding Machine Operation Instructions
Grinder before use Please provide the Chinese content to be translated.The megohmmeter measures the insulation resistance above 500 volts, with a value not less than 0.5 megohms.
2. The grinding wheel machine should be thoroughly inspected before use to check for any damage or cracks due to transportation. Pay special attention to any cracks in the grinding wheel. Lightly tap it with a wooden mallet; a clear, crisp sound indicates the item is in good condition.
3.Dust Removal Grinding Wheel MachineBefore use, manually rotate the shaft extension to check for smooth and quick movement, and listen for any grinding or rubbing noises.
4. The sanding machine and fan should rotate in the same direction as indicated by the rotation direction indicator.
