Calcium Carbonate Dryer, Calcium Carbonate Drying MachineCalcium Carbonate Flash DryerCalcium Carbonate Drying Equipment, Calcium Carbonate Drying MachineOperating Principle

Hot air enters the bottom of the dryer tangentially, forming a powerful rotational air field driven by the agitator. The paste-like material is introduced into the dryer by a spiral feeder, where it is dispersed under the intense action of the high-speed rotating impeller, subjected to impacts, friction, and shearing forces. The lumpy material is rapidly crushed, fully contacting the hot air, being heated, and dried. The dried material after dehydration rises with the hot air stream. The grading ring retains the larger particles, while the smaller particles are discharged from the center of the ring outside the dryer. They are recovered by the cyclone separator and dust collector. The material that is not fully dried or the larger pieces are thrown against the wall due to centrifugal force, falling back to the bottom to be crushed and dried again.

Calcium Carbonate Dryer, Calcium Carbonate Drying Machine, Calcium Carbonate Drying Equipment, Structure Diagram of Calcium Carbonate Drying Equipment:

Calcium Carbonate Dryer, Calcium Carbonate Drying MachineCalcium Carbonate Flash DryerCalcium Carbonate Drying Equipment, Calcium Carbonate Drying MachineryPerformance Features

The integrated application of vortex, fluidization, spray drying, and crushing classification technologies.

The equipment is compact, with a small footprint, and high production efficiency, enabling continuous production, achieving "small equipment, large output."

High drying intensity, low energy consumption, and high thermal efficiency.

Short material dwell time, high-quality finished products, suitable for drying heat-sensitive materials.

Negative or slightly negative pressure operation, good airtightness, high efficiency, and elimination of environmental pollution.

Material Compatible

Organic Compounds: Atrazine, lauric acid esters, benzoic acid, salicylic acid, chlorothalonil, sodium acetate, cellulose acetate, organic pigments, etc.

Dyes: Anthraquinone, black iron oxide, indigo pigment, butyric acid, titanium dioxide, zinc sulfide, various azo dye intermediates.

Inorganic substances: borax, calcium carbonate, hydroxides, copper sulfate, iron oxide, barium carbonate, antimony trioxide, various metal hydroxides, various heavy metal salts, synthetic cryolite, etc.

Food: Soy protein, gelling starch, lees, wheat sugar, wheat starch, etc.

Technical Specifications:

Note: 1. The water evaporation rate is the amount of water evaporated per hour when the inlet air temperature is 180°C and the outlet air temperature is 80°C.

2. In addition to the above models, we can offer special designs upon customer request.

3. The above installed capacity is the standard package; the package with different material power can be significantly reduced.
