Product Introduction:

The Shanghai Ta Chi QMC Quick Die Change System serves as a comprehensive solution to meet the JIT (Just-In-Time) and SMED (Single Minute Exchange of Die) requirements for small-lot, multi-category production in advanced manufacturing processes.

Operation Principle: A very short-duration (1-4 seconds) current pulse activates (magnetizes) the system, securing the mold to the machine's back panel without time constraints, without requiring continuous electrical power and without generating heat. A different current pulse alters the magnetic field direction of the permanent magnet in operation, demagnetizing the system and releasing the mold.

Product Advantages: QMC Quick Mold Change System - Safety Performance

Each pole in the MQC quick-change mold system is an independent magnetic area. The steel core, augmented with a high-energy neodymium-iron-boron (NdFeB) magnet encased in a 5-sided shell, ensures a concentrated and durable magnetic force (MMF).

Electromagnetic permanent magnet technology inherently boasts safety due to the clamping force always originating from the magnetic field of the magnetic material.

Electricity is used only during the magnetization and demagnetization processes.

No electrical power required during operation.

Proximity sensors detect in real-time the contact status between the mold and magnetic template.

FCS (Flux Current Sensor) monitors the actual magnetic condition

UCS (Magnetic Saturation Detection System) confirms magnetic energy conversion is in place

Safety key prevents accidental operation and unintended demagnetization
