Airflow: 0.8 – 129 m³/min
Pressure: 0.1-0.9 kgf/cm²
Motor Power: 0.75 - above 250 kW
Standard Accessories:
Universal Base
Belt Guard
Fan Belt Wheel, Motor Belt Wheel, V-Belt
Inhalation muffler (with air filter)
Safety valve
Pressure Gauge
Lubricant
Anchoring Bolt
Each model comes with a performance chart and standard specifications, making it easy to select the appropriate fan model.
The fan body, including the attachments, is standardized. We have a well-established mass production system, capable of meeting your requirements at any time.
Due to its excellent spiral structure and the use of a muffler with a silent air filter that matches the same fan, the fan operates at a significantly lower noise level than before.
The rotor is a precision product that has been numerically controlled machined. It has achieved complete dynamic balance during the manufacturing process, with minimal error and virtually no vibration.
Compact design, takes up minimal installation area.
