BFH-E-3/63
Performance Parameters
Rated Voltage: 220V / 380V
Allowable Current: 15A
Protection Level: IP55
Explosion-Proof Symbol: ExeⅡT 4GC
Dimensions: Tee: 165×82×45
Three-way Connector: 165×105×45
Insulation Resistance: ≥50 MQ
Applicable Electric Heat Trays: Constant Power Parallel Type
Self-limiting electric heating tape
Caution when Operating the Frequency
Find the junction box is cracked, stop using it immediately and replace it.
Tighten all fasteners during installation, strictly prohibit any interconnection between cores and resistive wires, ensuring normal electrical spacing.
The seal ring size should match the electrical heating tape model upon installation.
Excess connection holes must be sealed with the provided steel plate to ensure explosion-proof performance.
