6Mico Lighting Pneumatic Telescopic Pole

Internal Spiral Cable: 2x2.0sq.mm + 4x1.5sq.mm

Applied to
Emergency alarm vehicle
Firefighting Vehicles

3> Other Special Vehicle Applications

6-meter Vertical Lighting Aerial Lift Pole

Product Number: 70505060

1> Extended Height: 6m

2> Shrink Height: 1.75 meters

Internal Cable: 2x2.5mm²²+4x1.5mm²

4> Number of Sections: 5

Each section diameter: 66mm~140mm

6> Material: Anodized aluminum tube material AL6063/T5

The weight of the rod: Approximately 50kg

Operating Temperature Range: -40⁰C to +75⁰C

Anti-torque lock with safety valve and drain outlet valve

10> Recommended Lighting Control: 4x 1000W lamps
