Suitable for various indoor and outdoor work environments. Meets the needs of the Chinese coal industry, PetroChina, Sinopec, CNOOC, power, metallurgy, steel, shipping, aerospace, fire protection, chemical industry, and large enterprises for fixed emergency lighting.

The housing is made of lightweight alloy materials with a fully sealed design. The alloy housing ensures the product can withstand shocks and impacts, and can reliably operate in various corrosive environments. It boasts excellent electromagnetic compatibility and does not cause electromagnetic interference to the surrounding environment. The high-energy non-memory battery can be recharged, with a single charge retaining at least 80% of its capacity for one year and at least 50% for two years. It also features a low-voltage over-discharge protection circuit, reliably protecting the battery and extending its lifespan.

Integrated structure, aesthetically pleasing, compact in size, lightweight, and easy to maintain. Available in ceiling-mounted, suspended ceiling, and floor-standing installation options to meet lighting requirements in various working environments.

Rated Voltage: ~220V/50Hz

Rated Power: 5 x 1W Light Source: LED

Battery Capacity: h

Emergency Time: 12min

Shell protection grade: IP65

Insulation Grade: I

Corrosion Resistance Grade: WF2

Infeed Door Thread: G3/4

Cable Introduction: 8~10mm

Dimensions: 240*202*132mm

Total Weight: 6 Kg

Determine the installation method and location of the lighting fixtures based on the site environment and lighting requirements. Secure the lighting fixtures and electrical control boxes in place. Prepare a five-core cable line of the appropriate length, according to the distance between the lighting fixtures and the 220V AC power source.
