Variable Frequency Control Cabinet ZM806

VFD Cabinet Function Overview: Connects to external load units, enabling variable frequency speed control of load equipment while also providing protection for the connected loads. Standard controls include multi-step speed control, open-loop proportional follow speed control, closed-loop feedback control, and PID high-precision closed-loop control. Using a variable frequency drive can achieve energy and emission reduction, especially for high-capacity loads, with more pronounced effects. Direct on/off operations can be performed on the control cabinet, or remote control can be achieved via PLC or DCS systems through terminal outputs. Equipped with circuit breakers, contactors, variable frequency drives, thermal relays, buttons, indicator lights, and auxiliary control devices, it ensures safe and precise control of fans, pumps, and electric valves.

Arthos Electric Control Cabinet General Technical Parameters:

Manufacturing Standards:

       GB.7251.12-2013

Quality System Standards:

       GB/T19001-2008 IDT ISO9001:2008

Control Cabinet Parameters:

Rated Voltage

       380-420V/500-690V

Rated Current

       32A-6300A

3. Segmentation Capability

       ≥30KA

4. Cabinet Material

Cold rolled steel plate, stainless steel 304

5. Cabinet External Dimensions

Customized Non-standard Cabinet

       2000*300*600/800

       2000*600*600/800

       2000*800*600/800

       2000*1000*600/800

       2000*1200*600/800

6. Door Opening Method

Pre-order/After-order/Pre-order Double/After-order Single

7. Color

RAL 7032/RAL 7035/ZIMU standard colors

8. Protection Grade

       IP30/IP54/IP65

9. IK Impact Resistance to External Mechanical Shock

Steel Plate Body: IK 10

Control cabinet for steel plate glass front door: IK 08

Aroce cabinet structure:

Standard cabinet units, custom-made non-standard cabinets

Common Component Brands:

ABB, Schneider, Siemens, Mitsubishi, OMR, LS, Delixi, Renmin Electrical, Changshu Electrical, Weituo, IDEC.
