Note: For special products such as explosion-proof motors, DC motors, brake motors, single-phase motors, etc., please contact our company.
The travel adjustment mechanism can be optionally fitted with either a full-sealed proximity switch or a standard limit switch.
Electromagnetic actuators can reliably operate under the following conditions:
1. Operating temperature ranges between -10°C and 60°C.
2. Relative humidity below 85%.
3. Short-time work is below 25%.
4. The overload automatic protection switch should be correctly connected to the electrical control circuit.
5. Users must install the limit switches XW1 and XW2 themselves (excluding our company's electric push rods with adjustable stroke).
6. Allowable lateral load: (0.03-0.05) times rated thrust.
7. Start-up frequency: less than 4-5 times per minute.
Product Model Coding Rules
